DATA SHEET
SILICON POWER TRANSISTOR
2SA1741
PNP SILICON EPITAXIAL TRANSISTOR
FOR HIGH-SPEED SWITCHING
The 2SA1741 is a power transistor developed for high-speed
switching and features a high h
FE
at low V
CE(sat)
. This transistor is
ideal for use as a driver in DC/DC converters and actuators.
In addition, a small resin-molded insulation type package
contributes to high-density mounting and reduction of mounting
cost.
PACKAGE DRAWING (UNIT: mm)
FEATURES
• High h
FE
and low V
CE(sat)
:
h
FE
≥
100 (V
CE
=
−2
V, I
C
=
−1
A)
V
CE(sat)
≤
0.3 V (I
C
=
−3
A, I
B
=
−0.15
A)
• Full-mold package that does not require an insulating board or
bushing when mounting.
Electrode Connection
1. Base
2. Collector
3. Emitter
.
ABSOLUTE MAXIMUM RATINGS (Ta = 25°C)
°
Parameter
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current (DC)
Collector current (pulse)
Base current (DC)
Total power dissipation
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
*
I
B(DC)
P
T
(Tc = 25°C)
P
T
(Ta = 25°C)
T
j
T
stg
Ratings
−100
−60
−7.0
−5.0
−10
−2.5
25
2.0
150
−55
to +150
Unit
V
V
V
A
A
A
W
W
°C
°C
* PW
≤
300
µ
s, duty cycle
≤
50%
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. D16125EJ1V0DS00 (1st edition)
Date Published April 2002 N CP(K)
Printed in Japan
©
