2DD2678

Description
LOW VCE(SAT) NPN SURFACE MOUNT TRANSISTOR
File Size83KB,4 Pages
ManufacturerDiodes
Websitehttp://www.diodes.com/
Download Datasheet View All

2DD2678 Online Shopping

Suppliers Part Number Price MOQ In stock
2DD2678 - - View Buy Now

2DD2678 Overview

LOW VCE(SAT) NPN SURFACE MOUNT TRANSISTOR

2DD2678
LOW V
CE(SAT)
NPN SURFACE MOUNT TRANSISTOR
Please click here to visit our online spice models database.
Features
Epitaxial Planar Die Construction
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
Case: SOT89-3L
Case Material: Molded Plastic, "Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Finish — Matte Tin annealed over Copper leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking Information: See Page 3
Ordering Information: See Page 3
Weight: 0.072 grams (approximate)
COLLECTOR
2,4
3 E
C 4
2 C
1 B
TOP VIEW
Pin Out Configuration
1
BASE
3
EMITTER
Top View
Device Schematic
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
CM
I
C
Value
15
12
6
6
3
Unit
V
V
V
A
A
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Peak Pulse Current
Continuous Collector Current
Thermal Characteristics
Characteristic
Power Dissipation (Note 3) @ T
A
= 25°C
Thermal Resistance, Junction to Ambient Air (Note 3) @ T
A
= 25°C
Power Dissipation (Note 4) @ T
A
= 25°C
Thermal Resistance, Junction to Ambient Air (Note 4) @ T
A
= 25°C
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
P
D
R
θ
JA
T
J
, T
STG
Value
0.9
139
2
62.5
-55 to +150
Unit
W
°C/W
W
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
V
CE(SAT)
h
FE
C
obo
f
T
Min
15
12
6
270
Typ
90
26
170
Max
0.1
0.1
250
680
Unit
V
V
V
μA
μA
mV
pF
MHz
Conditions
I
C
= 10μA, I
E
= 0
I
C
= 1mA, I
B
= 0
I
E
= 10μA, I
C
= 0
V
CB
= 15V, I
E
= 0
V
EB
= 6V, I
C
= 0
I
C
= 1.5A, I
B
= 30mA
V
CE
= 2V, I
C
= 500mA
V
CB
= 10V, I
E
= 0,
f = 1MHz
V
CE
= 2V, I
C
= 100mA,
f = 100MHz
Characteristic
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 5)
Emitter-Base Breakdown Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
ON CHARACTERISTICS (Note 5)
Collector-Emitter Saturation Voltage
DC Current Gain
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
Current Gain-Bandwidth Product
Notes:
1.
2.
3.
4.
5.
No purposefully added lead.
Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
Device mounted on FR-4 PCB with minimum recommended pad layout.
Device mounted on FR-4 PCB with 1 inch
2
copper pad layout.
Measured under pulsed conditions. Pulse width = 300μs. Duty cycle
≤2%.
2DD2678
Document number: DS31637 Rev. 3 - 2
1 of 4
www.diodes.com
April 2010
© Diodes Incorporated
