DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK3058
SWITCHING
N-CHANNEL POWER MOS FET
INDUSTRIAL USE
DESCRIPTION
This product is N-Channel MOS Field Effect Transistor
designed for high current switching applications.
ORDERING INFORMATION
PART NUMBER
2SK3058
2SK3058-S
2SK3058-ZJ
5
Note
2SK3058-Z
PACKAGE
TO-220AB
TO-262
TO-263
TO-220SMD
Note
FEATURES
•
Super Low On-State Resistance
R
DS(on)1
= 17 mΩ MAX. (V
GS
= 10 V, I
D
= 28 A)
R
DS(on)2
= 27 mΩ MAX. (V
GS
= 4.0 V, I
D
= 28 A)
•
Low C
iss
: C
iss
= 2100 pF (TYP.)
•
Built-in Gate Protection Diode
TO-220SND package is produced only in
Japan.
ABSOLUTE MAXIMUM RATINGS (T
A
= 25 °C)
Drain to Source Voltage (V
GS
= 0)
Gate to Source Voltage (V
DS
= 0)
Gate to Source Voltage (V
DS
= 0)
Drain Current (DC)
Drain Current (Pulse)
Note1
(TO-220AB)
60
±20
+20, –10
±55
±165
58
1.5
150
–55 to + 150
27.5
75.6
V
V
V
A
A
W
W
°C
°C
A
mJ
(TO-262)
V
DSS
V
GSS(AC)
V
GSS(DC)
I
D(DC)
I
D(pulse)
P
T
P
T
T
ch
T
stg
Total Power Dissipation (T
C
= 25°C)
Total Power Dissipation (T
A
= 25°C)
Channel Temperature
Storage Temperature
Single Avalanche Current
Single Avalanche Energy
Note2
Note2
I
AS
E
AS
Notes 1.
PW
≤
10
µ
s, Duty cycle
≤
1 %
2.
Starting Tch = 25 °C, V
DD
= 30 V, R
G
= 25
Ω,
V
GS
= 20 V
→
0
(TO-263, TO-220SMD)
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No.
D13097EJ2V0DS00 (2nd edition)
Date Published April 2001 NS CP(K)
Printed in Japan
