BZT55C2V4 - BZT55C75
500mW, 5% Tolerance SMD Zener Diode
Small Signal Product
Features
◇
Wide zener voltage range selection : 2.4V to 75V
◇
V
Z
tolerance selection of ±5%
◇
Moisture sensitivity level 1
◇
Matte Tin(Sn) lead finish with Nickel(Ni) underplate
◇
Pb free version and RoHS compliant
◇
All external surfaces are corrosion resistant and
leads are readily solderable
QUADRO Mini-MELF (LS34)
Hermetically Sealed Glass
Mechanical Data
◇
Case : QUADRO Mini-MELF Package (JEDEC DO-213)
◇
High temperature soldering guaranteed : 270
o
C/10s
◇
Polarity : Indicated by cathode band
◇
Weight : 29 ± 2.5mg
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C ambient temperature unless otherwise specified.
Maximum Ratings
Parameter
Power Dissipation
Forward Voltage
Thermal Resistance (Junction to Ambient)
Junction and Storage Temperature Range
Note : Valid provided that electrodes are kept at ambient temperature.
I
F
=10mA
(Note 1)
Symbol
P
D
V
F
R
θJA
T
J
, T
STG
Value
500
1.0
500
-65 to +175
Unit
mW
V
o
C/W
o
C
Zener I vs. V Characteristics
V
BR
I
ZK
Z
ZK
I
ZT
V
Z
Z
ZT
I
ZM
V
ZM
: Voltage at I
ZK
: Test current for voltage V
BR
: Dynamic impedance at I
ZK
: Test current for voltage V
Z
: Voltage at current I
ZT
: Dynamic impedance at I
ZT
: Maximum steady state current
: Voltage at I
ZM
Document Number：DS_S1308005
Version : E13
Small Signal
Electrical Characteristics ( T
A
= 25
o
C unless otherwise noted )
V
F
Forward Voltage = 1.0V Maximum @ I
F
= 10 mA for all part numbers
Part Number
BZT55C2V4
BZT55C2V7
BZT55C3V0
BZT55C3V3
BZT55C3V6
BZT55C3V9
BZT55C4V3
BZT55C4V7
BZT55C5V1
BZT55C5V6
BZT55C6V2
BZT55C6V8
BZT55C7V5
BZT55C8V2
BZT55C9V1
BZT55C10
BZT55C11
BZT55C12
BZT55C13
BZT55C15
BZT55C16
BZT55C18
BZT55C20
BZT55C22
BZT55C24
BZT55C27
BZT55C30
BZT55C33
BZT55C36
BZT55C39
BZT55C43
BZT55C47
BZT55C51
BZT55C56
BZT55C62
BZT55C68
BZT55C75
V
Z
Nom
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
@ I
ZT
Min
2.28
2.51
2.8
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
40
44
48
52
58
64
70
(Volt)
Max
2.56
2.89
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.1
23.3
25.6
28.9
32
35
38
41
46
50
54
60
66
72
79
I
ZT
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Z
ZT
@ I
ZT
(Ω)
Max
85
85
85
85
85
85
75
60
35
25
10
8
7
7
10
15
20
20
26
30
40
50
55
55
80
80
80
80
80
90
90
110
125
135
150
160
170
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
600
600
600
600
600
600
600
600
550
450
200
150
50
50
50
70
70
90
110
110
170
170
220
220
220
220
220
220
220
500
600
700
700
1,000
1,000
1,000
1,000
I
R
@ V
R
(μA)
Max
50
10
4
2
2
2
1
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
V
R
(V)
1
1
1
1
1
1
1
1
1
1
2
3
5
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
28
32
35
38
42
47
51
56
Notes： 1. The Zener Voltage (V
Z
) is tested under pulse condition of 10ms.
2. The device numbers listed have a standard tolerance on the nomial zener voltage of ±5%.
3. For detailed information on price, availability and delivery of nominal zener voltages between the voltages
shown and tighter voltage tolerances, contact your nearest
Taiwan Semiconductor
representative.
4. The Zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an
RMS value equal to 10% of the dc zener current(I
ZT
or I
ZK
) is superimposed to I
ZT
or I
ZK
.
Document Number：DS_S1308005
Version : E13
Small Signal Product
RATINGS AND CHARACTERISTICS CURVES
Fig. 1 Typical Forward Characteristics
1000
T
A
=25
o
C
Forward Current (mA)
Zener Current (mA)
100
300
250
200
150
100
50
1
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Forward Voltage (V)
0
0
1
2
3
4
5
6
7
8
9
10
11
12
Zener Voltage (V)
T
A
=25
o
C
Fig. 2 Zener Breakdown Characteristics
10
Fig. 3 Zener Breakdown Characteristics
100
Power Dissipation (mW)
600
500
400
300
200
100
0
15
25
35
45
55
65
75
85
0
Fig. 4 Admissible Power Dissipation Curve
10
Zener Current (mA)
1
0.1
0.01
50
100
150
200
Zener Voltage (V)
Ambient Temperature (
o
C)
Fig. 5 Typical Capacitance
1000
1000
Fig. 6 Effect of Zener Voltage on Impedence
I
Z
=1mA
1V Bias
Dynamic Impedence(Ohm)
100
Capacitance (pF)
100
10
10
I
Z
=5mA
I
Z
=20mA
Bias at 50% of V
Z
(Nom)
1
1
10
Zener Voltage (V)
100
1
1
10
Zener Voltage (V)
100
Document Number：DS_S1308005
Version : E13
Small Signal Product
Ordering information (Example)
Part No.
BZT55CXX
(Note 1)
BZT55C2V4
BZT55C2V4
BZT55C2V4
Package
QMMELF
QMMELF
QMMELF
QMMELF
Packing
10K / 13" Reel
2.5K / 7" Reel
10K / 13" Reel
10K / 13" Reel
10K / 13" Reel
Packing code
L0
L1
L0
L0
L0
Packing code
(Green)
L0G
L1G
L0G
L0G
L0G
L0
B0
Manufacture code
(Note 2)
Note 1 : "xx" is Device Code from "2V4" thru "75".
Note 2 : Manufacture special control, if empty means no special control requirement.
Tape & Reel specification
Item
Carrier width
Carrier length
Carrier depth
Sprocket hole
Reel outside diameter
Reel inner diameter
Feed hole width
Sprocket hole position
Punch hole position
Sprocket hole pitch
Embossment center
Overall tape thickness
Tape width
Reel width
Symbol
A
B
C
d
D
D1
D2
E
F
P0
P1
T
W
W1
Dimension
1.83 ±0.10
3.73 ±0.10
1.80 ±0.10
1.50 ± 0.10
178 ± 1
55 Min
330 ± 1
100 Min
13.0 ± 0.20
1.75 ±0.10
3.50 ±0.05
4.00 ±0.10
2.00 ±0.05
0.23 ±0.005
8.00 ±0.30
14.4 Max
Document Number：DS_S1308005
Version : E13
Small Signal Product
Dimensions
C
DIM.
B
D
A
B
C
A
D
Unit(mm)
Min
3.30
1.40
0.20
1.8 TYP.
Max
3.70
1.60
0.45
Min
0.130
0.055
0.008
Unit(inch)
Max
0.146
0.063
0.018
0.071 TYP.
Suggested PAD Layout
DIM.
A
B
C
D
Unit(mm)
Typ.
1.25
2.00
2.50
5.00
Unit(inch)
Typ.
0.049
0.079
0.098
0.197
Document Number：DS_S1308005
Version : E13
