IA
NT
Features
■
■
■
■
Applications
■
■
■
RoHS compliant*
18 RC terminators tied to a common
node
Stable thin-film-on-silicon technology
Ultra-miniature packages to JEDEC
standards
High-speed bus termination
Low power consumption
Ideal for space-constrained applications
*R
oH
S
CO
M
PL
Thin Film on Silicon 2CTA AC Terminator x 18
General Information
Package Schematic
The AC Terminator is used to provide termination for clock
and data lines where transmission line effects would
otherwise cause wave reflections or signal ringing. These
Silicon-based, Tantalum-Nitride resistors and capacitors
feature excellent stability, temperature coefficients and
tracking performance. This product series conforms to
JEDEC standards.
20
19
18
17
16
15
14
13
12
11
1
2
3
4
5
6
7
8
9
10
Electrical & Environmental Characteristics
Electrical Characteristics
Resistance Range
Resistor Tolerance
Power Rating per Resistor @ 70 °C
Capacitor Range
Capacitor Tolerance
Capacitor Breakdown Voltage
Operating Voltage
Symbol
R
Minimum
33
Nominal
±10 %
Maximum
100
0.1
Unit
Ω
Ω
Watt
pF
pF
V
V
V
°C
°C
Watt
C
33
25
±20 %
35
180
50
2K
-55
-65
Environmental Characteristics
ESD
Operating Temperature
Storage Temperature
Power Rating per Package @ 70 °C
TJ
Tstg
+125
+150
1.0
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Thin Film on Silicon 2CTA AC Terminator x 18
Mechanical Characteristics
QSOP Package Dimensions
A
.635
TYP.
(.025)
3.81 - 3.99
(.150 - .157)
Model
2QSP20
A
8.56 - 8.74 (.337 - .344)
Governing dimensions are in mm. Dimensions in
parentheses are in inches and are approximate.
JEDEC Reference Number MO-137.
QSOP Package Power Temperature Derating Curve
PIN 1
.21 - .31
(.008 - .012)
1.35 - 1.75
(.053 - .069)
1.25
WATTS
1.0
.75
.50
.25
0
25
50
75
100
125
150
AMBIENT TEMPERATURE (
°
C )
2QSP20
.10 - .25
(.004 - .010)
Typical Part Marking
0-8
°
.19 - .25
(.007 - .010)
Represents total content. Layout may vary.
PRODUCT
FUNCTION
RESISTANCE CODE/
CAPACITANCE CODE
PIN 1 INDICATOR
(MOLDED INDENT)
MANUFACTURER'S
TRADEMARK
PIN COUNT
CTA20Q
470330M
YYWW
PACKAGE
STYLE
GRADE
5.80 - 6.20
(.228 - .244)
.41 - 1.27
(.016 - .050)
DATE CODE
Standard RC Values
R1
Value
(ohms)
100
33
47
C1
Value
(pF)
100
47
47
Cap.
BV
(typ.)
25
50
50
Part Number
(Tape & Reel)
2CTA101101MQ20R
2CTA330470MQ20R
2CTA470470MQ20R
Part Number
(Tubes)
2CTA101101MQ20T
2CTA330470MQ20T
2CTA470470MQ20T
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Thin Film on Silicon 2CTA AC Terminator x 18
Dispensing
For large quantities, the product will be dispensed in Tape and Reel (see diagram below).
A0
DIMENSIONS = MM (INCHES)
B0
K0
Package
QSOP
20 Pin
A0
6.5 (0.256)
B0
9.0 (0.354)
K0
2.1 (0.083)
Width
16 (0.630)
Pitch
8 (0.315)
No. of Pieces No. of Pieces
per 13 reel
per tube
3,500
56
How To Order
2 CTA101 101 M Q 20 R LF
Product Class
Thin-Film-on-Silicon
Product Function
CTA = AC Terminator x 18
Resistance Value Code
1st two digits are significant,
3rd digit = number of zeros to follow
to give resistance value in ohms.
Capacitance Code
1st two digits are significant,
3rd digit = number of zeros to follow
to give capacitor value in pF.
Standard Grade
R Tol.
C Tol.
M = ±10 %
±20 %
Standard Package Style
Q = QSOP
Pin Count
Q = 20
Dispensing
R = Reel
T = Tube
Terminations
LF = 100 % Sn (RoHS Compliant)
Asia-Pacific:
Tel: +886-2 2562-4117 • Fax: +886-2 2562-4116
Europe:
Tel: +41-41 768 5555 • Fax: +41-41 768 5510
The Americas:
Tel: +1-951 781-5500 • Fax: +1-951 781-5700
www.bourns.com
05/07
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
