DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SJ325,325-Z
SWITCHING
P-CHANNEL POWER MOS FET
DESCRIPTION
The 2SJ325 is P-channel MOS Field Effect Transistor designed for
solenoid, motor and lamp driver.
PACKAGE DRAWINGS (Unit: mm)
1.5
−0.1
+0.2
6.5 ±0.2
5.0 ±0.2
1.6 ±0.2
2.3 ±0.2
0.5 ±0.1
FEATURES
• Low On-state Resistance
R
DS(on)
= 0.08
Ω
TYP. (V
GS
=
−10
V, I
D
=
−2.0
A)
R
DS(on)
= 0.15
Ω
TYP. (V
GS
=
−4
V, I
D
=
−1.6
A)
• Low C
iss
: C
iss
= 800 pF TYP.
• Built-in G-S Gate Protection Diode
4
5.5 ±0.2
7.0 MIN.
13.7 MIN.
+0.2
1
2
3
1.1 ±0.2
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Drain to Source Voltage
Gate to Source Voltage (AC)
Gate to Source Voltage (DC)
Drain Current (DC)
Drain Current (pulse)
Note
0.5
−0.1
V
V
V
A
A
0.5
−0.1
+0.2
V
DSS
V
GSS(AC)
V
GSS(DC)
I
D(DC)
I
D(pulse)
P
T1
P
T2
T
ch
T
stg
−30
m20
−20,
+10
m4.0
m16
20
1.0
150
−55
to +150
2.3 2.3
0.75
<R>
TO-251 (MP-3)
5.0 ±0.2
4.4 ±0.2
4
5.5 ±0.2
1.5
−0.1
+0.2
Total Power Dissipation (T
C
= 25°C)
Total Power Dissipation (T
A
= 25°C)
Channel Temperature
Storage Temperature
W
W
°C
°C
6.5 ±0.2
2.3 ±0.2
0.5 ±0.1
Note
1.0 ±0.5
0.4 MIN.
0.5 TYP.
2.5 ±0.5
Note
5.6 ±0.3
9.5 ±0.5
1 2 3
Note
PW
≤
10
μ
s, Duty Cycle
≤
1%
0.5 ±0.1
0.5 ±0.1
2.3 ±0.3
2.3 ±0.3
0.15 ±0.15
EQUIVALENT CIRCUIT
TO-252 (MP-3Z)
Electrode Connection
1. Gate
2. Drain
3. Source
4. Drain Fin
Note
The depth of notch at the top of the fin is
from 0 to 0.2 mm.
