E & E Magnetic Products Limited

SHIELDED SURFACE MOUNT

POWER INDUCTOR

Drum Type, SISDR127 Series

CHEMATICS

Magnetically Shielded

Miniature in size and high energy storage

Ideal for high current requirements of notebook,

video recorders and other DC-DC conversion

applications

Custom inductance value or tolerance is available

RoHS compliant

LECTRICAL

PECIFICATION

@ 25

Part

Number

SISDR127M-R47R

SISDR127M-1R0R

SISDR127M-1R5R

SISDR127M-2R2R

SISDR127M-3R3R

SISDR127M-4R7R

SISDR127M-6R8R

SISDR127M-8R2R

SISDR127M-100R

SISDR127M-150R

SISDR127M-220R

SISDR127M-330R

SISDR127M-470R

SISDR127M-680R

SISDR127M-820R

SISDR127M-101R

SISDR127M-151R

SISDR127M-221R

SISDR127M-331R

SISDR127M-471R

SISDR127M-681R

SISDR127M-821R

SISDR127M-102R

SISDR127K-222R

Inductance

(uH)

0.419

0.821

1.357

2.027

2.831

4.841

7.387

8.861

10.47

14.09

22.93

33.92

47.05

66.48

79.75

99.31

144.9

221.5

323.6

467.1

676.7

818.1

1005

2200

Inductance

Tolerance

±20%

±10%

DCR

Typ)

1.81

2.47

3.27

3.88

5.67

9.17

11.6

15.7

17.2

24.7

39.1

60.0

71.9

105

143

163

247

376

574

861

1080

1470

1660

4200

Isat

(

)

Irms

(

)

18.6

15.9

13.8

12.7

10.5

8.25

Volt-mSec

Typ.

3.50

4.90

6.30

7.70

9.10

11.9

14.7

16.1

17.5

20.3

25.9

31.5

37.1

44.1

48.3

53.9

65.1

80.5

97.3

117

141

155

172

254.1

Marking

(XYYY)

MR47

M1R0

M1R5

M2R2

M3R3

M4R7

M6R8

M8R2

M100

M150

M220

M330

M470

M680

M820

M101

M151

M221

M331

M471

M681

M821

M102

K222

56.0

40.0

31.1

25.5

21.5

16.5

13.3

12.2

11.2

9.66

7.57

6.22

5.28

4.44

4.06

3.64

3.01

2.43

2.01

1.68

1.39

1.27

1.14

0.42

7.34

6.32

6.04

5.03

4.00

3.23

2.95

2.44

2.09

1.96

1.59

1.29

1.04

0.85

0.76

0.65

0.61

0.40

Notes:

1. Ordering Information: SISDR127a - bbbRc.

SISDR127 = Product Type.

= Tolerance of Inductance (M =

±20%,

K =

10%).

bbb

= Inductance value in uH (i.e. R47 =0.47uH; 4R7 = 4.7uH; 470 = 47uH; 471 = 470uH; 102 = 1000uH).

= Internal Control Code.

= Packaging Code (T = Tape & Reel Packaging in 13 inch Reel).

2. Inductance is tested at 0.25Vrms, 100kHz.

3. Saturation current, Isat, indicates the value of DC current when the inductance is 30% typical lower than its

initial value.

4. Heating current, Irms, is the value of current when the temperature rising

DT=40

C typical.

1/F., Harbour View 1, No.12 Science Park East Avenue, Phase II, Hong Kong Science Park, Shatin, N.T. Hong Kong

Tel: (852) 2954 3333

Fax: (852) 2954 3304

PI069(04)

Revised in 07/13
