DATA SHEET
NPN SILICON RF TRANSISTOR
2SC4571
NPN EPITAXIAL SILICON RF TRANSISTOR
FOR UHF TUNER OSC/MIX
3-PIN SUPER MINIMOLD
DESCRIPTION
The 2SC4571 is a low supply voltage transistor designed for UHF OSC/MIX.
It is suitable for a high density surface mount assembly since the transistor has been applied super minimold
package.
FEATURES
• High Gain Bandwidth Product
f
T
= 5.0 GHz TYP. @ V
CE
= 5 V, I
C
= 5 mA, f = 1 GHz
• Low Output Capacitance
C
ob
= 0.9 pF TYP. @ V
CB
= 5 V, I
E
= 0 mA, f = 1 MHz
• 3-pin super minimold Package
ORDERING INFORMATION
Part Number
2SC4571
2SC4571-T1
Quantity
50 pcs (Non reel)
3 kpcs/reel
• 8 mm wide embossed taping
• Pin 3 (collector) face to perforation side of the tape
Supplying Form
Remark
To order evaluation samples, contact your nearby sales office.
The unit sample quantity is 50 pcs.
ABSOLUTE MAXIMUM RATINGS (T
A
= +25°C)
Parameter
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current
Total Power Dissipation
Junction Temperature
Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
tot
Note
Ratings
20
12
3
60
120
125
−55
to +125
Unit
V
V
V
mA
mW
°C
°C
T
j
T
stg
Note
Free air
Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices
representative for availability and additional information.
Document No. PU10513EJ01V0DS (1st edition)
(Previous No. P10409EJ2V0DS00)
Date Published October 2004 CP(K)
Printed in Japan
The mark
shows major revised points.
©
NEC Compound Semiconductor Devices, Ltd. 1993, 2004
