Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
5.0
10.0
25.0
50.0
75.0
100.0
0.390
0.290
0.260
0.250
0.260
0.270
-32.90
-26.30
-20.10
-25.10
-34.70
-46.90
9.940
10.560
10.790
10.790
10.690
10.520
-151.50
-168.30
176.20
162.50
150.80
140.00
0.050
0.050
0.050
0.050
0.060
0.060
-151.80
-172.10
169.90
154.50
139.80
126.90
0.260
0.150
0.120
0.170
0.200
0.220
-19.90
-23.60
8.60
18.80
15.60
8.50
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
