BH30SA3WGUTE2

Description
Fixed Positive Standard Regulator, 3VCMOS, PBGA4,
CategoryPower/power management    The power supply circuit
File Size1MB,17 Pages
ManufacturerROHM Semiconductor
Websitehttps://www.rohm.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BH30SA3WGUTE2 Overview

Fixed Positive Standard Regulator, 3VCMOS, PBGA4,

BH30SA3WGUTE2 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerROHM Semiconductor
package instructionFBGA, BGA4,2X2,20
Reach Compliance Codecompliant
ECCN codeEAR99
AdjustabilityFIXED
Nominal dropback voltage 10.5 V
Maximum absolute input voltage6.5 V
JESD-30 codeS-PBGA-B4
Maximum grid adjustment rate0.02%
Maximum load regulation0.045%
Output times1
Number of terminals4
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Maximum output current 10.15 A
Nominal output voltage 13 V
Package body materialPLASTIC/EPOXY
encapsulated codeFBGA
Encapsulate equivalent codeBGA4,2X2,20
Package shapeSQUARE
Package formGRID ARRAY, FINE PITCH
method of packingTAPE AND REEL
Certification statusNot Qualified
Regulator typeFIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
surface mountYES
technologyCMOS
Terminal formBALL
Terminal pitch0.5 mm
Terminal locationBOTTOM
Maximum voltage tolerance1%
CMOS LDO Regulators for Portable Devices
1ch 150mA
CMOS LDO Regulators
BH□□SA3WGUT Series
No.11020EAT10
●Description
The BH□□SA3WGUT Series are 150 mA output CMOS regulators that deliver a highly stable output voltage with the
precision of ± 1%. With the use of ROHM’s original technology, the load regulation of only 2 mV, 100 mV I/O drop voltage,
and the load transient of 50mV (at 1mA⇔100mA) have been achieved. The VCSP60N1 package is extremely compact as
just 0.96 mm × 0.96 mm, and the IC's enhanced protection circuits contribute to improved application safety.
●Features
1) High accuracy output voltage: ± 1%
2) I/O drop voltage: 100 mV (at 100 mA)
3) Load Transient
⊿Vout
: 50mV (at 1mA⇔100mA)
4) Stable with ceramic capacitors (1µF)
5) Low bias current: 40 µA
6) High ripple rejection ratio: 63 dB (Typ., 1 kHz)
7) Output voltage on/off control
8) Built-in overcurrent (short) and thermal shutdown circuits
9) Uses the VCSP60N1 WL-CSP package.
●Applications
Battery-driven portable devices, etc.
●Product
Line
■150
mA
BH□□SA3WGUT Series
1.8
○
2.8
3.0
Package
VCSP60N1
Product name
BH□□SA3WGUT
Model name: BH□□SA3W□
a
b
Symbol
Description
Output voltage specification
□□
18
Output voltage (V)
1.8 V (Typ.)
2.8 V (Typ.)
3.0 V (Typ.)
a
28
30
b
Package GUT: VCSP60N1
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
1/14
2012.02 - Rev.A

BH30SA3WGUTE2 Related Products

BH30SA3WGUTE2 BH18SA3WGUTE2 BH28SA3WGUTE2
Description Fixed Positive Standard Regulator, 3VCMOS, PBGA4, Fixed Positive Standard Regulator Fixed Positive Standard Regulator, 2.8VCMOS, PBGA4,
Is it Rohs certified? conform to conform to conform to
Maker ROHM Semiconductor ROHM Semiconductor ROHM Semiconductor
package instruction FBGA, BGA4,2X2,20 , FBGA, BGA4,2X2,20
Reach Compliance Code compliant compliant compliant
ECCN code EAR99 EAR99 EAR99
Regulator type FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Adjustability FIXED - FIXED
Nominal dropback voltage 1 0.5 V - 0.5 V
Maximum absolute input voltage 6.5 V - 6.5 V
JESD-30 code S-PBGA-B4 - S-PBGA-B4
Maximum grid adjustment rate 0.02% - 0.02%
Maximum load regulation 0.045% - 0.045%
Output times 1 - 1
Number of terminals 4 - 4
Maximum operating temperature 85 °C - 85 °C
Minimum operating temperature -40 °C - -40 °C
Maximum output current 1 0.15 A - 0.15 A
Nominal output voltage 1 3 V - 2.8 V
Package body material PLASTIC/EPOXY - PLASTIC/EPOXY
encapsulated code FBGA - FBGA
Encapsulate equivalent code BGA4,2X2,20 - BGA4,2X2,20
Package shape SQUARE - SQUARE
Package form GRID ARRAY, FINE PITCH - GRID ARRAY, FINE PITCH
method of packing TAPE AND REEL - TAPE AND REEL
Certification status Not Qualified - Not Qualified
surface mount YES - YES
technology CMOS - CMOS
Terminal form BALL - BALL
Terminal pitch 0.5 mm - 0.5 mm
Terminal location BOTTOM - BOTTOM
Maximum voltage tolerance 1% - 1%
