M38279EFGP: Description8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 14 MM, 0.50 MM PITCH, PLASTIC, LQFP-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size838KB，71 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

M38279EFGP Overview

8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 14 MM, 0.50 MM PITCH, PLASTIC, LQFP-100

M38279EFGP Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	QFP
package instruction	LFQFP,
Contacts	100
Reach Compliance Code	unknown
Has ADC	YES
Other features	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY
Address bus width
bit size	8
maximum clock frequency	8 MHz
DAC channel	YES
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G100
length	14 mm
Number of I/O lines	64
Number of terminals	100
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
Certification status	Not Qualified
ROM programmability	OTPROM
Maximum seat height	1.7 mm
speed	4 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

To all our customers

Regarding the change of names mentioned in the document, such as Mitsubishi

Electric and Mitsubishi XX, to Renesas Technology Corp.

The semiconductor operations of Hitachi and Mitsubishi Electric were transferred to Renesas

Technology Corporation on April 1st 2003. These operations include microcomputer, logic, analog

and discrete devices, and memory chips other than DRAMs (flash memory, SRAMs etc.)

Accordingly, although Mitsubishi Electric, Mitsubishi Electric Corporation, Mitsubishi

Semiconductors, and other Mitsubishi brand names are mentioned in the document, these names

have in fact all been changed to Renesas Technology Corp. Thank you for your understanding.

Except for our corporate trademark, logo and corporate statement, no changes whatsoever have been

made to the contents of the document, and these changes do not constitute any alteration to the

contents of the document itself.

Note : Mitsubishi Electric will continue the business operations of high frequency & optical devices

and power devices.

Renesas Technology Corp.

Customer Support Dept.

April 1, 2003

M38279EFGP Related Products

	M38279EFGP	M38277M8MXXXHP	M38279EF-XXXGP	M38279EF-XXXHP	M38279EF-XXXFP	M38277M8MXXXFP	M38277M8MXXXGP	M38279EFFS	M38279EFFP	M38279EFHP
Description	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 14 MM, 0.50 MM PITCH, PLASTIC, LQFP-100	8-BIT, MROM, 4MHz, MICROCONTROLLER, PQFP100, 12 X 12 MM, 0.40 MM PITCH, PLASTIC, TQFP-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 14 MM, 0.50 MM PITCH, PLASTIC, LQFP-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 12 X 12 MM, 0.40 MM PITCH, PLASTIC, TQFP-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 20 MM, 0.65 MM PITCH, PLASTIC, QFP-100	8-BIT, MROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 20 MM, 0.65 MM PITCH, PLASTIC, QFP-100	8-BIT, MROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 14 MM, 0.50 MM PITCH, PLASTIC, LQFP-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, CQCC100, WINDOWED, CERAMIC, QFN-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 14 X 20 MM, 0.65 MM PITCH, PLASTIC, QFP-100	8-BIT, OTPROM, 4MHz, MICROCONTROLLER, PQFP100, 12 X 12 MM, 0.40 MM PITCH, PLASTIC, TQFP-100
Parts packaging code	QFP	QFP	QFP	QFP	QFP	QFP	QFP	QFN	QFP	QFP
package instruction	LFQFP,	TFQFP,	LFQFP,	TFQFP,	QFP,	QFP,	LFQFP,	WQCCN,	QFP,	TFQFP,
Contacts	100	100	100	100	100	100	100	100	100	100
Reach Compliance Code	unknown	compliant	compliant	compliant	unknown	unknown	unknown	compliant	compliant	compliant
Has ADC	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
Other features	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY	ALSO OPERATES AT 2.2 V MINIMUM SUPPLY
bit size	8	8	8	8	8	8	8	8	8	8
maximum clock frequency	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz	8 MHz
DAC channel	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
DMA channel	NO	NO	NO	NO	NO	NO	NO	NO	NO	NO
JESD-30 code	S-PQFP-G100	S-PQFP-G100	S-PQFP-G100	S-PQFP-G100	R-PQFP-G100	R-PQFP-G100	S-PQFP-G100	R-CQCC-N100	R-PQFP-G100	S-PQFP-G100
length	14 mm	12 mm	14 mm	12 mm	20 mm	20 mm	14 mm	21 mm	20 mm	12 mm
Number of I/O lines	64	64	64	64	64	64	64	64	64	64
Number of terminals	100	100	100	100	100	100	100	100	100	100
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C
PWM channel	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	TFQFP	LFQFP	TFQFP	QFP	QFP	LFQFP	WQCCN	QFP	TFQFP
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	RECTANGULAR	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, THIN PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, THIN PROFILE, FINE PITCH	FLATPACK	FLATPACK	FLATPACK, LOW PROFILE, FINE PITCH	CHIP CARRIER, WINDOW	FLATPACK	FLATPACK, THIN PROFILE, FINE PITCH
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
ROM programmability	OTPROM	MROM	OTPROM	OTPROM	OTPROM	MROM	MROM	OTPROM	OTPROM	OTPROM
Maximum seat height	1.7 mm	1.2 mm	1.7 mm	1.2 mm	3.05 mm	3.05 mm	1.7 mm	5 mm	3.05 mm	1.2 mm
speed	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4 V	4 V	4 V	4 V	4 V	4 V	4 V	4 V	4 V	4 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER	OTHER
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	NO LEAD	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.4 mm	0.5 mm	0.4 mm	0.65 mm	0.65 mm	0.5 mm	0.65 mm	0.65 mm	0.4 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD
width	14 mm	12 mm	14 mm	12 mm	14 mm	14 mm	14 mm	15.6 mm	14 mm	12 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Maker	Renesas Electronics Corporation	-	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation
