Model LPE-6855
Vishay Dale
Transformers/Inductors
Surface Mount, Gapped and Ungapped
Custom Configurations Available
ELECTRICAL SPECIFICATIONS
(Multiple winds are connected in parallel)
Inductance Range:
10µH to 150000µH, measured at 0.10V RMS @ 10kHz
without DC current, using an HP 4263 or HP 4284A impedance analyzer.
DC Resistance Range:
0.02 ohm to 46.2 ohm, measured at + 25°C
±
5°C.
Operating Temperature:
- 20°C to + 80°C.
Rated Current Range:
3.20 amps to .17 amps.
Dielectric Withstanding Voltage:
500V RMS, 60Hz, 5 seconds.
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE
(
µ
H)
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10000
15000
22000
33000
47000
68000
100000
150000
INDUCTANCE
TOLERANCE
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
30%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
±
20%
SCHEMATIC
LETTER
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
DCR
MAX.
(Ohms)
MAX. RATED*
DC CURRENT
(Amps)
SATURATING**
CURRENT
(Amps)
MODEL
Ungapped Models
LPE-6855-151NA
LPE-6855-221NA
LPE-6855-331NA
LPE-6855-471NA
LPE-6855-681NA
LPE-6855-102NA
LPE-6855-152NA
LPE-6855-222NA
LPE-6855-332NA
LPE-6855-472NA
LPE-6855-682NA
LPE-6855-103NA
LPE-6855-153NA
LPE-6855-223NA
LPE-6855-333NA
LPE-6855-473NA
LPE-6855-683NA
LPE-6855-104NA
LPE-6855-154NA
Gapped Models
LPE-6855-100MB
LPE-6855-150MB
LPE-6855-220MB
LPE-6855-330MB
LPE-6855-470MB
LPE-6855-680MB
LPE-6855-101MB
LPE-6855-151MB
LPE-6855-221MB
LPE-6855-331MB
LPE-6855-471MB
LPE-6855-681MB
LPE-6855-102MB
LPE-6855-152MB
LPE-6855-222MB
LPE-6855-332MB
LPE-6855-472MB
0.28
0.34
0.41
0.49
0.59
0.72
0.88
1.07
1.31
1.56
1.88
7.17
8.78
10.6
13.0
15.5
18.7
37.7
46.2
.84
.76
.69
.63
.57
.52
.47
.43
.39
.35
.32
.16
.15
.14
.12
.11
.10
.07
.06
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
B
B
B
B
B
B
B
C
D
D
D
E
E
E
E
E
E
0.02
0.03
0.04
0.05
0.08
0.12
0.15
0.23
0.35
0.55
0.82
1.23
1.89
2.90
4.50
5.50
8.30
3.21
2.90
2.64
2.12
1.73
1.41
1.28
1.02
.83
.67
.54
.45
.36
.29
.23
.21
.17
3.375
2.790
2.325
1.910
1.610
1.350
1.120
.915
.757
.620
.520
.433
.358
.292
.242
.197
.166
*DC current that will create a maximum temperature rise of 30°C when applied at + 25°C ambient. **DC current that will typically reduce the initial inductance by
20%.
UNGAPPED MODELS:
Highest possible inductance with the lowest DCR and highest Q capability. Beneficial in filter, impedance matching and line coupling
devices.
GAPPED MODELS:
Capable of handling large amounts of DC current, tighter inductance tolerance with better temperature stability than ungapped models.
Beneficial in DC to DC converters or other circuits carrying DC currents or requiring inductance stability over a temperature range.
www.vishay.com
76
Document Number 34067
Revision 27-Apr-99
Model LPE-6855
Vishay Dale
DIMENSIONAL CONFIGURATIONS
[Numbers in brackets indicate millimeters]
Pad Layout
0.045 [1.14] Pad Dimensions
Typical, 8 places
5
0.079 [2.01]
0.045
[1.14]
0.593
[15.06]
0.638
[16.21]
Reference Only
Typical 3
places
8
Clip Opening
Opposite Pin 1
1
4
.555
[14.10]
Max.
.690 [17.53]
Max.
.079
[2.01]
Typ.
Dimensional Outline
.618
[15.70]
.028
[.71]
.220 [5.59]
Max.
.028
[.71]
Foot print Diagram
NOTE:
Pad layout guidelines per MIL-STD-275E (printed wiring for electronic equipment). Tolerances: xx
±
.01" [± 0.25mm]. xxx
±
.005" [± 0.12mm].
SCHEMATICS (Top View)
Schematic A
5
6
7
8
4
5
3
6
2
1
7
8
Schematic B
4
3
2
1
5
6
7
8
Schematic C
4
3
2
1
5
6
7
8
Schematic D
4
3
2
1
5
6
7
8
Schematic E
4
3
2
1
NOTE:
Schematic A is for Ungapped LPE Series.
ENVIRONMENTAL PERFORMANCE
TEST
Thermal Cycling
High Temperature
High Humidity
Soldering Heat
Mechanical Shock
Vibration
Solderability
CONDITIONS
Withstands - 55°C to +125°C
+ 85°C
85%
Tested to + 230°C
Per MIL-STD-202, Method 214 (100G)
Per MIL-STD-202, Method 204 (20G)
Per industry standards
PART MARKING
— Vishay Dale
— Date code
— Marking code (Suffix of model #)
— Pin 1 indicator
HOW TO ORDER - LPE-6855-102NA
LPE
MODEL
6855
SIZE
1000
µ
H
INDUCTANCE VALUE
±
30%
INDUCTANCE TOLERANCE
A
CORE
PACKAGING
TAPE SPECIFICATIONS:
Carrier Tape Type: Conductive.
Cover Tape Type: Anti-static.
Cover Tape Adhesion to Carrier: 40
±
30 grams.
REEL SPECIFICATIONS:
Diameter (flange): 13" [330.2mm].
Maximum Width (over flanges): 1.197" [30.4mm].
STANDARDS:
All embossed carrier tape packaging will be
accomplished in compliance with latest revision of EIA-481
“Taping of Surface Mount Components for Automatic Placement”.
MODEL
LPE-6855
TAPE
WIDTH
32mm
COMPONENT
PITCH
20mm
UNITS PER
13 INCH REEL
450
Tape and Reel Orientation
Pin 1
Indicator
Cover Tape
Carrier Tape
Label Area
USER DIRECTION OF FEED
Embossed Cavity
NOTE:
Top view shown with cover tape removed.
Document Number 34067
Revision 27-Apr-99
www.vishay.com
77
