Cross Reference Guide
PN7216 / SPN7216*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
10.0 - 500.0 MHz
25.5 dB Typical
24.0 dB Min
2.5 dB Typical
3.0 dB Max
20.0 dBm Typical
18.0 dBm Min
33.0 dBm Typical
44.0 dBm Typical
1.8/2.0 Input Typ/Max
1.5/2.0 Output Typ/Max
-32.0 dB Typical
-30.0 dB Min
12.0 Volts
65.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
10.0
50.0
100.0
200.0
300.0
400.0
500.0
0.160
0.140
0.150
0.190
0.210
0.240
0.310
-29.00
-43.00
-69.00
-115.00
-154.00
173.00
135.00
20.160
19.770
19.350
18.910
18.600
18.700
18.020
9.00
-26.00
-55.00
-110.00
-166.00
135.00
72.00
0.010
0.010
0.010
0.010
0.020
0.030
0.030
1.00
-30.00
-69.00
-123.00
173.00
135.00
88.00
0.090
0.080
0.060
0.050
0.100
0.170
0.200
-137.00
171.00
145.00
149.00
127.00
77.00
23.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
15.0 Volts
50.0 mW
