2SC4690
TOSHIBA Transistor Silicon NPN Triple Diffused Type
2SC4690
Power Amplifier Applications
Unit: mm
•
•
•
High breakdown voltage: V
CEO
= 140 V (min)
Complementary to 2SA1805
Suitable for use in 70-W high fidelity audio amplifier’s output stage
Maximum Ratings
(Tc = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
(Tc = 25°C)
Junction temperature
Storage temperature range
DC
Pulse
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
j
T
stg
Rating
140
140
5
10
20
1
80
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
2-16F1A
Weight: 5.8 g (typ.)
Electrical Characteristics
(Tc = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
= 140 V, I
E
= 0
V
EB
= 5 V, I
C
= 0
I
C
= 50 mA, I
B
= 0
V
CE
= 5 V, I
C
= 1 A
V
CE
= 5 V, I
C
= 5 A
I
C
= 7 A, I
B
= 0.7 A
V
CE
= 5 V, I
C
= 5 A
V
CE
= 5 V, I
C
= 1 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Min
―
―
140
55
35
―
―
―
―
Typ.
―
―
―
―
85
0.3
0.9
30
220
Max
5.0
5.0
―
160
―
2.0
1.5
―
―
V
V
MHz
pF
Unit
µA
µA
V
Note: h
FE (1)
classification
R: 55 to 110, O: 80 to 160
1
2004-07-07
