2SC5029
TOSHIBA Transistor Silicon NPN Epitaxial Type (PCT Process)
2SC5029
Power Amplifier Applications
Power Switching Applications
Industrial Applications
Unit: mm
•
•
•
•
Low saturation voltage: V
CE (sat)
= 0.5 V (max) (I
C
= 1 A, I
B
= 0.05 A)
High collector power dissipation: P
C
= 1.3 W
High-speed switching: t
stg
= 1.0 µs (typ.)
Complementary to 2SA1892
Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
50
50
5
3
0.2
1.3
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
2-8M1A
Weight: 0.55 g (typ.)
1
2004-07-07
2SC5029
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter saturation voltage
Transition frequency
Collector output capacitance
Turn-on time
V
CE (sat)
V
BE (sat)
f
T
C
ob
t
on
I
B1
Test Condition
V
CB
= 50 V, I
E
= 0
V
EB
= 5 V, I
C
= 0
I
C
= 10 mA, I
B
= 0
V
CE
= 2 V, I
C
= 0.5 A
V
CE
= 2 V, I
C
= 1.5 A
I
C
= 1 A, I
B
= 0.05 A
I
C
= 1 A, I
B
= 0.05 A
V
CE
= 2 V, I
C
= 0.5 A
V
CB
= 10 V, I
C
= 0, f = 1 MHz
Output
30
Ω
Min
―
―
50
70
40
―
―
―
―
―
Typ.
―
―
―
―
―
―
―
100
30
0.1
Max
1.0
1.0
―
240
―
0.5
1.2
―
―
―
V
V
MHz
pF
Unit
µA
µA
V
20 µs
Input
I
B2
I
B1
I
B2
Switching time
Storage time
t
stg
―
1.0
―
µs
30 V
Fall time
t
f
I
B1
=
−I
B2
= 0.05 A, duty cycle
≤
1%
―
0.1
―
Note: h
FE (1)
classification
O: 70 to 140, Y: 120 to 240
Marking
C5029
Part No. (or abbreviation code)
Lot No.
Characteristics
indicator
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
2
2004-07-07
2SC5029
r
th
– t
w
1000
500
300
Curves should be applied in thermal limited area. (single nonrepetitive pulse)
Ta = 25°C
(°C /W)
r
th
Transient thermal resistance
100
50
30
10
5
3
I
B2
0.3
0.1
0.001
0.01
0.1
1
10
100
1000
Pulse width
t
w
(s)
Safe Operating Area
1.6
10
5
P
C
– Ta
P
C
(W)
Collector power dissipation
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
0
IC max (pulsed)*
IC max (continuous)
10 ms*
1 ms*
100 ms*
I
C
(A)
Collector current
3
1
0.5
DC operation
Ta = 25°C
*: Single nonrepetitive pulse
Ta = 25°C
0.05
Curves must be derated
0.03 linearly with increase in
temperature.
0.02
0.3
1
3
0.1
25
50
75
100
125
150
175
VCEO max
10
30
100
Ambient temperature
Ta
(°C)
Collector-emitter voltage
V
CE
(V)
4
2004-07-07
