SPECIFICATIONS
Voltage rating:
Current rating:
Contact pin material:
Contact pin plating:
Contact resistance:
Housing material:
Withstanding:
Operating temperature:
Processing temperature:
Circuits:
250 volts
See table
Brass (0.64mm sq.)
Bright tin
10 milliohms max.
Nylon 66, 30% glass fill, UL94V-0, black
1,500VAC for 1 min.
-25°C to +85°C
240°C/5 sec.
2 to 24
Dimensions
Pos. A
B
2
6.0
4
3.0 9.0
6
6.0 12.0
8
9.0 15.0
10 12.0 18.0
12 15.0 21.0
14 18.0 24.0
15 21.0 27.0
18 24.0 30.0
20 27.0 33.0
22 30.0 36.0
24 33.0 39.0
Plating
XX
Blank=Tin (std)
GD=Gold
A
B
C
C
D
Current rating
Wire size Amps
AWG 20
5
AWG 22
5
AWG 24
4
AWG 26
3
AWG 28
2
AWG 30
1
D
E
E
Series
JS-A
Pluggable Connector
F
RoHS compliant
Rev.
A
B
C
D
1
Type
3045
Vertical Header
3045=Kinked Pins (std)
3045S=Straight Pins
Positions
Options
XX
XXX
02S-12S Single Row Blank=Centering Peg (std)
02-24 Dual Row
BL2=2mm Board Lock
BL3=3.2mm Board Lock
F
G
Description
RoHS, spec
Spec
P/N
PNT
2
Date
09/20/05
10/04/05
10/30/07
01/18/13
Approved
Tom
Tom
Tom
Greg
3
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
4
Date
08/10/99
08/10/99
08/10/99 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
JS-A-3045-XX-XX
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Header, 3mm pitch, dual row, vertical
