SHC SHCD SHCS SHCSD
■
■
■
.100 GRID SURFACE MOUNT COMMERCIAL/INDUSTRIAL RELAYS
SHC SHCS
■
SHCD SHCSD
■
STANDARD • SENSITIVE
.100 GRID SURFACE MOUNT COM-
MERCIAL RELAY
STANDARD • SENSITIVE
.100 GRID SURFACE MOUNT
DIODE SUPPRESSED
COMMERCIAL RELAY
_
+
TERMINAL VIEW
TERMINAL VIEW
FEATURES
■
■
FEATURES
■
■
■
Hermetically sealed
Excellent RF switching
Suppression Diode
Hermetically sealed
Excellent RF switching
ELECTRICAL CHARACTERISTICS
CONTACT ARRANGEMENT
ELECTRICAL CHARACTERISTICS
COIL VOLTAGE
2 Form C (DPDT)
CONTACT MATERIAL
5 to 26.5 Vdc (SHC/SHCD)
5 to 48 Vdc (SHCS/SHCSD)
COIL POWER
Stationary:
Gold/platinum/palladium/silver alloy
(gold plated)
Moveable:
Gold/platinum/palladium/silver alloy
(gold plated)
CONTACT RESISTANCE
SHC/SHCD:
660 mW max. @ 25°C
SHCS/SHCSD:
565 mW max. @ 25°C
DUTY CYCLE
Continuous
PICK-UP VOLTAGE
Before Life:
100 milliohms max.
(measured @ 10 mA @ 6 Vdc)
After Life:
200 milliohms max.
(measured @ 1 A @ 28 Vdc)
MECHANICAL LIFE EXPECTANCY
Approximately 70% of
nominal coil voltage
PICK-UP SENSITIVITY
1 million operations
SHC/SHCD:
180 mW max. @ 25°C
SHCS/SHCSD:
90 mW max. @ 25°C
CONTACT RATINGS
CONTACT
LOAD
TYPE
OPERATIONS
MIN.
1.0 A @ 28 Vdc
250 mA @ 115 Vac, 60 Hz & 400 Hz
100 mA @ 115 Vac, 60 Hz & 400 Hz
0.2 A @ 28 Vdc
0.1 A @ 28 Vdc
30 µA @ 50 mVdc
Resistive
100,000
Resistive (Case not grounded) 100,000
Resistive
100,000
Inductive (0.32 Henry)
100,000
Lamp
100,000
Low Level
1,000,000
28
Tyco Electronics Corporation www.tycoelectronics.com 800-522-6752 (U.S.A.) or 717-564-0100 Specifications subject to change. CII and TYCO are trademarks. ©2003 by Tyco Electronics Corporation
SHC SHCD SHCS SHCSD
■
■
■
.100 GRID SURFACE MOUNT COMMERCIAL/INDUSTRIAL RELAYS
OPERATING CHARACTERISTICS
TIMING
STANDARD COIL DATA
NOM.
COIL
VOLTAGE
(Vdc)
COIL
RESISTANCE
IN OHMS
±20% @ 25°C
PICKUP
VOLTAGE
Vdc (MAX.)
@ 25°C
NOM. COIL
POWER
(mW)
@ 25°C
MAX.
COIL
VOLTAGE
COIL
DESIG.
OperateTime:
SHC/SHCD: 4.0 ms max.
SHCS/SHCSD: 6.0 ms max.
ReleaseTime:
SHC: 3.0 ms max.
SHCS: 3.0 ms max.
SHCD: 6.0 ms max.
(suppression diode)
SHCSD: 7.5 ms max.
(suppression diode)
DIELECTRIC WITHSTANDING VOLTAGE
SHC/SHCD
5.0
6.0
9.0
12.0
18.0
26.5
64
98
220
400
880
1,600
100
200
400
800
1,600
3,200
6,500
11,000
3.8
4.9
7.0
9.0
14.0
18.0
3.5
4.5
6.8
9.0
13.5
18.0
24.0
32.0
391
367
368
360
368
439
250
180
203
180
203
219
199
209
5.8
8.0
12.0
16.0
24.0
32.0
7.5
10.0
15.0
20.0
30.0
40.0
57.0
75.0
5
6
9
12
18
26
5
6
9
12
18
26
36
48
Between Open Contacts:
350 Vrms 60 Hz
Between Adjacent Contacts:
350 Vrms 60 Hz
Between Contacts & Coil:
350 Vrms 60 Hz
INSULATION RESISTANCE
SHCS/SHCSD
5.0
6.0
9.0
12.0
18.0
26.5
36.0
48.0
1,000 megohms @ 500 Vdc
ENVIRONMENTAL CHARACTERISTICS
TEMPERATURE RANGE
.335 (8.51) SQ MAX
.378
+.030/–.020
(9.60) TYP
.031
±
.003
(0.79)
.035
±
.010
(0.98)
REF
-55°C to + 85°C
WEIGHT
SHC/SHCD:
0.09 oz. (2.55 gms)
SHCS/SHCSD:
0.15 oz. (4.30 gms)
VIBRATION RESISTANCE
.280 (7.11)
MAX
.360 (9.14)
MAX
.375 (9.53)
SQ MAX
2°
±2°
TYP
±4°
TYP
.100
(2.54)
TYP
8 PLS
10 G’s, 10 to 500 Hz
SHOCK RESISTANCE
30 G’s, 6 ±1 ms
SEMICONDUCTOR CHARACTERISTICS
DIODE
SHC/SHCD ENCLOSURE
SHC/SHCD/SHCS/SHCSD HEADER
100 Vdc peak inverse voltage (PIV)
1.0 Vdc max. transient voltage
.335 (8.51) SQ MAX
.410 (10.41) MIN
.045
(1.14) MIN.
8 PLCS
.380 (9.65)
MAX
.460 (11.68)
MAX
.410 (10.41)
MIN
.200
(5.08)
2°
±2°
TYP
.100
(2.54)
4 PLCS
.200 (5.08)
SHCS/SHCSD ENCLOSURE
RECOMMENDED
SOLDER PAD LAYOUT
SPECIFYING A PART NUMBER EXAMPLE
:
TYPE
DIODES
GROUND PIN
COILS
SHC
D
X
-26
29
Tyco Electronics Corporation www.tycoelectronics.com 800-522-6752 (U.S.A.) or 717-564-0100 Specifications subject to change. CII and TYCO are trademarks. ©2003 by Tyco Electronics Corporation
