F-209-2
SCPU–17–G–3.00–AMS–BMS
SCRUS–17–G–0.25–AMS–BC
IP68 USB CIRCULAR
SCPU, SCRUS SERIES
Mates with:
SCRUS
SCPU
SPECIFICATIONS
For complete specifications
see www.samtec.com?SCPU
Insulator Material:
Glass Filled
Thermoplastic
Contact Material:
Copper Alloy
Shield Material:
CRS
Wire:
Wire gauge varies based
on length to meet USB 2.0
specifications. Call Samtec for
more information.
Sealed Overmold:
PA66 GF13 FR
Operating Temp Range:
-20°C to +75°C
RoHS Compliant:
Yes
SHELL
SIZE
PLATING
WIRE
LENGTH
END 1
OPTION
END 2
OPTION
See chart for available
combinations
–G
–17
(Standard USB only)
= 30µ"
(0,76µm)
Gold on
Contact,
Nickel on
Shell
–2.00
= (2m) 79" Cable
–AMS
= USB A Type,
Sealed
–3.00
= (3m) 118" Cable
–AMS
= USB A Type, Sealed
= USB B Type, Sealed
(-17 only)
–10
(Mini USB only)
(42,00) 1.65
–BMS
= USB B Type,
Sealed
–5.00
= (5m) 197" Cable
(Assembled Length
= Wire Length
+ (19,5) .77)
–BMS
–MBS
–AM
–BM
–MBS
= Mini USB B
Type, Sealed
(–10 only)
(28,00)
1.102
= Mini USB B Type,
Sealed
(–10 only)
ALSO AVAILABLE
Other wire lengths.
Dust Cap: DCA-17-02
Contact Samtec.
APPLICATION SERIES
ETHERNET
SCPE
POWER
SCP1
HIGH DENSITY SCP2
TIGER EYE
™
SCP3
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–MBS
–AMS
–BMS
= USB A Type,
Not Sealed
= USB B Type,
Not Sealed
(-17 only)
–BM
–MB
–AM
ALSO
AVAILABLE
Dust Cap: DCA-17-01
Panel Plug: SCPPA-17-01
= Mini USB B Type,
Not Sealed
(-10 only)
–MB
Mates with:
SCPU
TYPE
SHELL
SIZE
PLATING
SPECIFICATIONS
For complete specifications and
recommended panel hole layout
see www.samtec.com?SCRUS
Insulator Material:
PBT
Contact Material:
Phosphor Bronze
O-Ring:
Silicone
Operating Temp Range:
-20°C to +75°C
RoHS Compliant:
Yes
WIRE
LENGTH
END 1
OPTION
END 2
OPTION
See chart
for available
combinations
SCRUS
= Sealed Circular
USB Receptacle
Cable Assembly
–17
(Standard
USB only)
–G
= 30µ" (0,76µm)
Gold on Contact,
Nickel on Shell
–0.25
= (0,25m) 9.84" Cable
–AMS
= USB A Type, Sealed
–10
(Mini
Note:
Some lengths,
USB only)
styles and options are
non-standard,
non-returnable.
APPLICATION
–0.50
= (0,50m) 19.68" Cable
(Assembled Length
= Wire Length
+ (37,9) 1.50)
–BMS
= USB B Type, Sealed
–AM
= USB A Type,
Not Sealed
–MBS
= Mini USB B Type, Sealed
–BM
= USB B Type,
Not Sealed
ALSO AVAILABLE
USB Flash Drive Cover:
DCA–17–03
SPECIFIC
Termination for
standard USB cable
from panel to board
–MB
= Mini USB B
Type, Not Sealed
(48,45)
1.907
Device dimensions
80,00mm x 13,30mm x
20,25mm max.
–MBS
(31,80)
1.252 (39,50)
1.55
DIA
–BC
= Blunt Cut
–AMS
–AMS
WWW.SAMTEC.COM
