SINGLE-IN-LINE SOCKETS
Solder Tail
Single Row
2,54
2,54
2,54
0,38
0,25
0,64
0,46
●
●
Series 310, 311, 315
SIP sockets accept 0,38 - 0,64
diameter pins and standard IC leads.
Various solder tails available:
standard length, long for multi-
layer boards, very low and ultra
low profile. See Mill-Max #1001,
0134, 0501 or 1534 pins (pages
130, 131, 134) for details.
Hi-Rel, 4-finger BeCu #12 & #30
clips rated at 3 amps. See pages
207 & 208 for details.
2,41
2,79
3,71
4,19
●
0,51
3,18
Ordering Information
Fig. 1
0,38
0,25
0,64
0,46
Series 310...001
Standard Solder Tail
Fig. 1
4,19
310-XX-1_ _-41-001000
Specify # of pins
01-64
Long Solder Tail
2,62
2,79
3,81
Series 311...001
0,51
4,32
Fig. 2
311-XX-1_ _-41-001000
Specify # of pins
01-64
Very Low Profile
Fig. 2
0,38
0,25
0,64
0,46
Series 315...001
Fig. 3
3,1
315-XX-1_ _-41-001000
Specify # of pins
01-64
Ultra Low Profile
2,44
2,79
3,84
Series 315...003
2,74
Fig. 4
315-XX-1_ _-41-003000
Specify # of pins
01-64
0,76
Fig. 3
0,38
0,25
0,56
0,46
1,8
1,8
3,94
2,41
2,41
XX=Plating Code
See Below
For RoHS compliance,
select
plating code.
For the all gold option
(XX=13) also change
part number from
31X-XX-1XX-41-00X000
to
31X-13-1XX-41-00X100
0,76
SPECIFY PLATING CODE XX=
13
0,76µm Au
91
10µ” Au
93
0,76µm Au
99
41
43
44
Fig. 4
Sleeve (Pin)
Contact (Clip)
0,25µm Au
200µ” Sn/Pb
5,08µm Sn/Pb 5,08µm Sn/Pb
200µ” Sn
5,08µm Sn 5,08µm Sn
5,08µm Sn/Pb
10µ” Au
0,76µm Au 5,08µm Sn
w w w. m i l l - m a x . c o m
46
516-922-6000
