BZX84C24 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZX84C24

BZX84C24: Description24 V, 0.41 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE; CategoryDiscrete semiconductor diode; File Size339KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

BZX84C24 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BZX84C24	-	-	View	Buy Now

BZX84C24 Overview

24 V, 0.41 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE

BZX84C24 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Parts packaging code	SOT-23
package instruction	SOT-23, 3 PIN
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	PROELECTRON SPECIFICATION
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	70 Ω
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.35 W
Certification status	Not Qualified
Nominal reference voltage	24 V
surface mount	YES
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5.79%
Working test current	5 mA

Preview

Download Datasheet

View All

BZX84C2V4

THRU

BZX84C47

SURFACE MOUNT

SILICON ZENER DIODE

350mW, 2.4 THRU 47 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR BZX84C2V4

Series are surface mount silicon Zener diodes. These

high quality voltage regulating diodes are designed

for use in industrial, commercial, entertainment and

computer applications.

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

350

-65 to +150

357

ELECTRICAL CHARACTERISTICS:

(TA=25°C), VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

BZX84C2V4

BZX84C2V7

BZX84C3V0

BZX84C3V3

BZX84C3V6

BZX84C3V9

BZX84C4V3

BZX84C4V7

BZX84C5V1

BZX84C5V6

BZX84C6V2

BZX84C6V8

BZX84C7V5

BZX84C8V2

BZX84C9V1

BZX84C10

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.4

7.0

7.7

8.5

9.4

NOM

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

MAX

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

TEST

CURRENT

IZT

5.0

MAXIMUM

ZENER

IMPEDENCE

ZZT @ IZT

100

ZZK @ IZK

600

500

480

400

150

100

150

1.0

MAXIMUM

REVERSE

CURRENT

μA

5.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

1.0

2.0

4.0

5.0

6.0

7.0

MAXIMUM

ZENER

VOLTAGE

TEMP.

CURRENT

COEFF.

IZM

ΘV

104

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

TYPE

MARKING

CODE

Tolerance Code

Tolerance

±1%

±2%

Part Number Identification

B Z X 84 C 4V 7

Nominal Value Code(i.e. 4.7 Volts)

Tolerance Code

Device Series

R7 (20-November 2009)
