CMF16A: DescriptionSURFACE MOUNT UNI-DIRECTIONAL SILICON TRANSIENT VOLTAGE SUPPRESSOR 200 WATTS; CategoryDiscrete semiconductor diode; File Size604KB，4 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMF16A Overview

SURFACE MOUNT UNI-DIRECTIONAL SILICON TRANSIENT VOLTAGE SUPPRESSOR 200 WATTS

CMF16A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	SOD
package instruction	R-PDSO-F2
Contacts	2
Manufacturer packaging code	SOD-123F
Reach Compliance Code	_compli
ECCN code	EAR99
Other features	LOW LEAKAGE CURRENT
Maximum breakdown voltage	19.7 V
Minimum breakdown voltage	17.8 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-F2
JESD-609 code	e0
Maximum non-repetitive peak reverse power dissipation	200 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	16 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

CMF5.0A

THRU

CMF170A

SURFACE MOUNT

UNI-DIRECTIONAL SILICON

TRANSIENT VOLTAGE SUPPRESSOR

200 WATTS, 5.0 THRU 170 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMF5.0 Series

of Transient Voltage Suppressors are designed to

protect sensitive electronic components from high

voltage, high-energy transients. High surge capability,

low impedance, low clamping voltage, fast response

time and small size make this an excellent choice for

industrial/consumer applications, such as cell phones,

power supplies and portable devices.

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

FEATURES:

SOD-123F CASE

APPLICATIONS:

•

Digital cameras

Cell phones and accessories

Desktop and laptop computers

PDAs

•

Stand-off voltage 5 to 170 Volts

Very low leakage current

Low clamping voltage

200 Watt peak power dissipation

Small, high thermal efficiency, SOD-123F flat lead package

SYMBOL

PPP

VESD

TJ, Tstg

UNITS

°C

MAXIMUM RATINGS:

(TA=25°C)

Peak Pulse Power (10/1000µs Waveform)

ESD Voltage (HBM)

Operating and Storage Junction Temperature

200

-65 to +150

ELECTRICAL CHARACTERISTICS:

(TJ=25°C unless otherwise noted)

Reverse

Stand-Off

Voltage

Type

VRWM

CMF5.0A

CMF6.0A

CMF6.5A

CMF7.0A

CMF7.5A

CMF8.0A

CMF8.5A

CMF9.0A

CMF10A

CMF11A

CMF12A

CMF13A

CMF14A

CMF15A

CMF16A

CMF17A

CMF18A

5.0

6.0

6.5

7.0

7.5

8.0

8.5

9.0

Breakdown

Voltage

VBR @ IT

MIN

6.4

6.67

7.22

7.78

8.33

8.89

9.44

11.1

12.2

13.3

14.4

15.6

16.7

17.8

18.9

MAX

7.0

7.37

7.98

8.6

9.21

9.83

10.4

11.1

12.3

13.5

14.7

15.9

17.2

18.5

19.7

20.9

22.1

Test

Current

1.0

Reverse

Leakage

Current

IR @ VRWM

µA

400

250

100

5.0

2.5

1.0

Maximum

Clamping

Voltage

VC @ IPP

9.2

10.3

11.2

12.9

13.6

14.4

15.4

18.2

19.9

21.5

23.2

24.4

27.6

29.2

Peak

Pulse

Current

IPP

21.7

19.4

17.9

16.7

15.5

14.7

13.9

11.8

10.1

9.3

8.6

8.2

7.7

7.2

6.8

CM05A

CM06A

CM065

CM07A

CM075

CM08A

CM085

CM09A

CM10A

CM11A

CM12A

CM13A

CM14A

CM15A

CM16A

CM17A

CM18A

Marking

Code

R3 (8-January 2010)
