General Purpose Relays
SCHRACK
Power Relay T92
n
n
n
n
n
n
n
2 pole 30 A, 2 CO or 2 NO contacts
High switching capacity up 30 A / 400 VAC
DC- or AC coil
4 kV / 8 mm coil-contact
Insulation to VDE 0631 and VDE 0700
PCB- or quick connect terminals or chassis mount
Adapter for DIN-rail mounting
T92_group
Applications
Power supplies, heating & ventilation, control equipment
Approvals
V
REG.-Nr. 5386,
U
E22575,
C
LR15734
Technical data of approved types on request
Contact data
Contact configuration
2 NO contacts
2 CO contacts
Contact set
single contact
Type of interruption
micro disconnection
Rated voltage / max. switching voltage AC
400 / 600 VAC
Rated current
NO contact (PCB / flange mount)
30 / 20 A
30 / 20 A
NC contact
3A
Maximum breaking capacity AC, NO / NC contact 12 kVA
12 / 1.2 kVA
Contact material
AgCdO
Minimum contact load
500mA, 12V
Rated frequency of operation with / without load
7 min
-1
/ 300 min
-1
Operate- / release time (including bounce)
25 / 25 ms
Contact ratings
Type
UL 508
T92 AgCdO,
T92 AgCdO,
T92 AgCdO
T92 AgCdO
IEC 61810
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
T92 AgCdO,
DC coil
AC coil
ContactLoad
CO
CO
CO
CO
CO
CO
CO
CO
NO
NO
NO
NO
30 A
30 A
30 A
20 A
/
/
/
/
3A
3A
3A
3A
Ambient
temp. [°C]
277 VAC, resistive
277 VAC, resistive
277 VAC, gen. purp.
28 VDC, resisitive
25°C
25°C
25°C
25°C
85°C
65°C
85°C
65°C
85°C
65°C
85°C
65°C
Cycles
250x10
3
100x10
3
100x10
3
100x10
3
30x10
3
30x10
3
30x10
3
30x10
3
100x10
3
100x10
3
100x10
3
100x10
3
PCB, DC coil
PCB, AC coil
flange, DC coil
flange, AC coil
PCB, DC coil
PCB, AC coil
flange, DC coil
flange, AC coil
30 A/ 3 A, 400 VAC, cosϕ=1
30 A/ 3 A, 400 VAC, cosϕ=1
20 A/ 3 A, 400 VAC, cosϕ=1
20 A/ 3 A, 400 VAC, cosϕ=1
30 A 400 VAC, cosϕ=1
30 A 400 VAC, cosϕ=1
20 A 400 VAC, cosϕ=1
20 A 400 VAC, cosϕ=1
Coil data
Rated coil voltage range DC coil
AC coil
Operative range to IEC 61810
5...110 VDC
24...240 VAC
1
1
Datasheet Rev. IJ1
Issued 2009/10
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information only
to be used together with the
'Definitions' section in the cat-
alogue or at schrackrelays.com
in the ‘Schrack’ section.
Specifications subject to
change.
General Purpose Relays
SCHRACK
Power Relay T92
(Continued)
Coil versions, DC-coil
Coil
Rated
Operate
Release
Coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
mW
12
12
9.0
1.2
86+10%
1674
24
24
18.0
2.4
350+10%
1646
48
48
36.0
4.8
1390+10%
1658
110
110
83.0
11.0
7255+10%
1668
All figures are given for coil without preenergization, at ambient temperature +23°C
Other coil voltages on request
Coil versions, AC-coil 50 / 60 Hz
Coil
Rated
Frequ.
Operate
Release
DC-coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VAC
Hz
VAC
VAC
Ohm
VA
24
24
60
19.2
2.4
37+10%
4
120
110 / 120
50 / 60
96.0
12.0
950+10%
4
240
220 / 240
50 / 60
192.0
24.0
3800+10%
4
All figures are given for coil without preenergization, at ambient temperature +23°C
Other coil voltages on request
Insulation
Insulation resistance coil-contact circuit
Dielectric strength coil-contact circuit
open contact circuit
adjacent contact circuits
Clearance / creepage coil-contact circuit
Tracking index of relay base
Insulation to IEC 61810-1
Type of insulation coil-contact circuit
open contact circuit
adjacent contact circuits
Rated insulation voltage
Pollution degree
Rated voltage system
Overvoltage category
< 10
9
Ohms
4000 V
rms
1500 V
rms
2000 V
rms
W
5.5 / 8 mm
PTI 250
basic
micro disconnection
basic
250 V
3
250 V
III
PCB layout / terminal assignment
Bottom view on solder pins
Other data
Mechanical endurance
>5x10
6
cycles
Material
RoHS - Directive 2002/95/EC
compliant per product date code 0509
Environment
Ambient temperature range DC-coil
-40...+85°C
AC-coil
-40...+65°C
Vibration resistance (function) NO / NC contact 1.65 mm, 10...55 Hz
Shock resistance (function) NO / NC contact
10 g, 11 ms half sine
Shock resistance (destruction)
100 g, 11 ms half sine
Category of protection
RT I (dust protected)
RT III (wash tight)
Processing
Relay weight
86 g
Packaging unit
30 pcs
PCB version
S0262-AA
Dimensions
PCB version
S0262-AI
Only necessary terminals are present on 2 NO
models.
S0292-A
2
Datasheet Rev. IJ1
Issued 2009/10
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information only
to be used together with the
'Definitions' section in the cat-
alogue or at schrackrelays.com
in the ‘Schrack’ section.
Specifications subject to
change.
General Purpose Relays
SCHRACK
Power Relay T92
(Continued)
Dimensions
Flange mount
M4 screw terminals
S0495-A
S0293-A
Only necessary terminals are present on 2 NO models.
Product key
Type
Typical product key
T92
P
7
A
2
2
-24
T92
Power relay T92
Enclosure
P
dust protected
S
wash tight (PCB version only)
Contact configuration
7
2 NO contacts (2 form A)
11
2 CO contacts (2 form C)
Coil version
A
AC-coil 50/60 Hz
D
DC-coil
Mounting
1
PCB-version
2
Flange mount, 6.35 mm quick connect terminals for contacts and coil
5
M4 scew terminals (requires enclosure P and contact configuration 7, UL/CSA approved only)
Contact material
2
AgCdO
Coil
Coil code: please refer to coil versions table
Other types on request
Product key
T92P11A22-24
T92P11A22-240
T92P7A22-120
T92P7A22-240
T92P7D12-12
T92P7D22-12
T92P7D22-24
T92S11A12-240
T92S11A22-240
T92S11D12-24
T92S7A12-240
T92S7A22-240
T92S7D12-24
T92S7D22-24
Version
dust-proof
Mounting
flange mount
Cont.configuration
2 CO contacts
2 NO contacts
Coil
AC-coil
pcb-version
flange mount
wash tight
pcb-version
flange mount
pcb-version
flange mount
pcb-version
flange mount
2 CO contacts
2 NO contacts
DC-coil
AC-coil
DC-coil
AC-coil
DC-coil
Coil
24 VAC
240 VAC
120 VAC
240 VAC
12 VDC
24 VDC
240 VAC
24 VDC
240 VAC
24 VDC
Part number
4-1393211-3
4-1393211-4
5-1393211-7
6-1393211-2
6-1393211-5
6-1393211-9
7-1393211-1
8-1393211-2
8-1393211-7
9-1393211-0
9-1393211-9
1393212-5
1-1393212-0
1-1393212-7
3
Datasheet Rev. IJ1
Issued 2009/10
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information only
to be used together with the
'Definitions' section in the cat-
alogue or at schrackrelays.com
in the ‘Schrack’ section.
Specifications subject to
change.
