M83513/04-A06C: Description9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE; CategoryThe connector The connector; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

M83513/04-A06C Overview

9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE

M83513/04-A06C Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	STANDARD: MIL-DTL-83513
body width	0.298 inch
subject depth	0.224 inch
body length	0.775 inch
Body/casing type	RECEPTACLE
Connector type	D MICROMINIATURE CONNECTOR
Contact arrangement	S9P0
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	STAGGERED
Contact resistance	8 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	600VAC V
Durability	500 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	2.78 N
Insulation resistance	5000000000 Ω
insulator material	POLYPHENYLENE SULFIDE
MIL compliance	YES
Plug contact pitch	0.05 inch
Match contact row spacing	0.043 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	HOLE .094
Installation type	CABLE
Number of connectors	ONE
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
Plating thickness	50u inch
Rated current (signal)	3 A
Guideline	MIL
Shell surface	CADMIUM
Shell material	METAL
Housing size	A
Termination type	CRIMP
Total number of contacts	9
Maximum wire diameter	24 AWG
Minimum wire diameter	26 AWG
Evacuation force-minimum value	0.139 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Pin & Socket C onnectors

Product Feature Selector

> Product Details

M83513/04-A06C Product Details

Live Product Chat

Microminiature D Connectors

Not EU R oHS or ELV C om plia nt

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

M83513/04-A06C

(1-1532013-7)

T E I nternal N umber: 1 - 1 5 3 2 0 1 3 - 7

Product Highlights:

Product Series = MC K (Full Metal)

C able C onnector

C admium, Yellow C hromate Shell Plating

Number of Positions = 9

C ontact Type = Socket

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

METAL SHELL ''D'' C ONNEC TOR, RC PT MC K PER MIL-C -83513

(PDF, English)

Catalog Pages/Data Sheets:

MIC RODOT C ATALOG

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Series = MC K (Full Metal)

Product Type = C able C onnector

Number of Positions = 9

C omment = Also available in commercial grade.

Mechanical Attachment:

Mounting Hardware = None

Lead Length (mm [in]) = 25.40 [1.000]

Body Related Features:

Shell Plating = C admium, Yellow C hromate

Wire Size (AWG/C M) = 25 AWG

Wire Type = Solid C opper - Gold Plated

Contact Related Features:

C ontact Type = Socket

C ontact Style = Wire Termination

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material = Gold (50) per MIL-G-45204

Housing Related Features:

Housing Material = Polyphenylene Sulfide

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C , Reflow

solder capable to 245?C , Reflow solder capable to 260?C , Pin-in-

Paste capable to 245?C , Pin-in-Paste capable to 260?C

Other:

Brand = Microdot

Additional Information:

Product Line Information

M83513/04-A06C Related Products

	M83513/04-A06C	1-1532013-7
Description	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR
Is it Rohs certified?	incompatible	incompatible
Reach Compliance Code	unknown	unknow
Connector type	D MICROMINIATURE CONNECTOR	D MICROMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE
Contact material	NOT SPECIFIED	COPPER ALLOY
DIN compliance	NO	NO
empty shell	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
insulator material	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE
MIL compliance	YES	NO
Mixed contacts	NO	NO
Installation type	CABLE	CABLE
Options	GENERAL PURPOSE	GENERAL PURPOSE
Shell surface	CADMIUM	CADMIUM/CHROMATE
Shell material	METAL	METAL
Housing size	A	A
Total number of contacts	9	9
