M83513/04-A06N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> M83513/04-A06N

M83513/04-A06N: Description9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE, ROHS COMPLIANT; CategoryThe connector The connector; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

M83513/04-A06N Overview

9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE, ROHS COMPLIANT

M83513/04-A06N Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	STANDARD: MIL-DTL-83513
body width	0.298 inch
subject depth	0.224 inch
body length	0.775 inch
Body/casing type	RECEPTACLE
Connector type	D MICROMINIATURE CONNECTOR
Contact arrangement	S9P0
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	STAGGERED
Contact resistance	8 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	600VAC V
Durability	500 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	2.78 N
Insulation resistance	5000000000 Ω
insulator material	POLYPHENYLENE SULFIDE
MIL compliance	YES
Plug contact pitch	0.05 inch
Match contact row spacing	0.043 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	HOLE .094
Installation type	CABLE
Number of connectors	ONE
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
Plating thickness	50u inch
Rated current (signal)	3 A
Guideline	MIL
Shell surface	NICKEL
Shell material	METAL
Housing size	A
Termination type	CRIMP
Total number of contacts	9
Maximum wire diameter	24 AWG
Minimum wire diameter	26 AWG
Evacuation force-minimum value	0.139 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Pin & Socket C onnectors

Product Feature Selector

> Product Details

M83513/04-A06N Product Details

Live Product Chat

Microminiature D Connectors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

M83513/04-A06N

(2-1532013-4)

T E I nternal N umber: 2 - 1 5 3 2 0 1 3 - 4

Product Highlights:

Product Series = MC K (Full Metal)

C able C onnector

Nickel, Electroless Shell Plating

Number of Positions = 9

C ontact Type = Socket

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

METAL SHELL ''D'' C ONNEC TOR, RC PT MC K PER MIL-C -83513

(PDF, English)

Catalog Pages/Data Sheets:

MIC RODOT C ATALOG

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Series = MC K (Full Metal)

Product Type = C able C onnector

Number of Positions = 9

C omment = Also available in commercial grade.

Mechanical Attachment:

Mounting Hardware = None

Lead Length (mm [in]) = 25.40 [1.000]

Body Related Features:

Shell Plating = Nickel, Electroless

Wire Size (AWG/C M) = 25 AWG

Wire Type = Solid C opper - Gold Plated

Contact Related Features:

C ontact Type = Socket

C ontact Style = Wire Termination

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material = Gold (50) per MIL-G-45204

Housing Related Features:

Housing Material = Polyphenylene Sulfide

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C , Reflow

solder capable to 245?C , Reflow solder capable to 260?C , Pin-in-

Paste capable to 245?C , Pin-in-Paste capable to 260?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Other:

Brand = Microdot

Additional Information:

Product Line Information

M83513/04-A06N Related Products

	M83513/04-A06N	2-1532013-4
Description	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE, ROHS COMPLIANT	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknow
ECCN code	EAR99	EAR99
Other features	STANDARD: MIL-DTL-83513	WAVE SOLDER CAPABLE & 36" WIRE
body width	0.298 inch	0.298 inch
subject depth	0.224 inch	0.223 inch
body length	0.775 inch	1.175 inch
Body/casing type	RECEPTACLE	PLUG
Connector type	D MICROMINIATURE CONNECTOR	D MICROMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE
Contact material	NOT SPECIFIED	NOT SPECIFIED
contact mode	STAGGERED	STAGGERED
Contact resistance	8 mΩ	25 mΩ
Contact style	RND PIN-SKT	RND PIN-SKT
DIN compliance	NO	NO
Dielectric withstand voltage	600VAC V	750VAC V
empty shell	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
maximum insertion force	2.78 N	2.78 N
Insulation resistance	5000000000 Ω	5000000000 Ω
insulator material	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE
MIL compliance	YES	NO
Plug contact pitch	0.05 inch	0.05 inch
Mixed contacts	NO	NO
Installation option 1	HOLE .094	HOLE .087-.098
Installation type	CABLE	CABLE
Number of rows loaded	2	2
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C
Options	GENERAL PURPOSE	GENERAL PURPOSE
Plating thickness	50u inch	50u inch
Rated current (signal)	3 A	3 A
Shell surface	NICKEL	NICKEL
Shell material	METAL	METAL
Housing size	A	A
Termination type	CRIMP	SOLDER LUG
Total number of contacts	9	9
Maximum wire diameter	24 AWG	26 AWG
Minimum wire diameter	26 AWG	26 AWG
