CMPZDA18V datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> CMPZDA18V

CMPZDA18V: Description36 V, 0.35 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE; CategoryDiscrete semiconductor diode; File Size404KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMPZDA18V Overview

36 V, 0.35 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE

CMPZDA18V Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Parts packaging code	SOT-23
package instruction	SOT-23, 3 PIN
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	45 Ω
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Maximum knee impedance	225 Ω
Number of components	2
Number of terminals	3
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.35 W
Certification status	Not Qualified
Nominal reference voltage	18 V
Maximum reverse current	0.05 µA
surface mount	YES
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Voltage temperatureCoeff-Max	14.4 mV/°C
Maximum voltage tolerance	6.41%
Working test current	5 mA

Preview

Download Datasheet

View All

CMPZDA2V4 THRU CMPZDA47V

SURFACE MOUNT

DUAL, COMMON ANODE

SILICON ZENER DIODES

2.4 VOLTS THRU 47 VOLTS

350mW

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMPZDA2V4

Series silicon dual zener diode is a high quality voltage

regulator, connected in a common anode configuration,

for use in industrial, commercial, entertainment and

computer applications.

MARKING CODE: SEE MARKING CODES ON

ELECTRICAL CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

350

-65 to +175

429

UNITS

°C

°C/W

ELECTRICAL CHARACTERISTICS:

(TA=25°C) VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

CMPZDA2V4

CMPZDA2V7

CMPZDA3V0

CMPZDA3V3

CMPZDA3V6

CMPZDA3V9

CMPZDA4V3

CMPZDA4V7

CMPZDA5V1

CMPZDA5V6

CMPZDA6V2

CMPZDA6V8

CMPZDA7V5

CMPZDA8V2

CMPZDA9V1

CMPZDA10V

CMPZDA11V

CMPZDA12V

CMPZDA13V

CMPZDA15V

CMPZDA16V

CMPZDA18V

CMPZDA20V

CMPZDA22V

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.5

7.0

7.7

8.5

9.4

10.4

11.4

12.4

13.8

15.3

16.8

18.8

20.8

MAX

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

11.6

12.7

14.1

15.6

17.1

19.1

21.2

23.3

TEST

CURRENT

MAXIMUM

ZENER IMPEDANCE

MAXIMUM

REVERSE

CURRENT

μA

5.0

2.0

1.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

0.1

0.05

1.0

2.0

4.0

5.0

6.0

7.0

8.0

10.5

11.2

12.6

14.0

15.4

MAXIMUM

ZENER

VOLTAGE

CURRENT

TEMP.

COEFF.

IZM

9.2

8.3

7.6

ΘV

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

0.08

0.09

WW3

WW4

WW5

WW6

WW7

WW8

WW9

ZZ1

ZZ2

ZZ3

ZZ4

ZZ5

ZZ6

ZZ7

ZZ8

ZZ9

YY1

YY2

YY3

YY4

YY5

YY6

YY7

YY8

TYPE

MARKING

CODE

IZT

5.0

ZZT @ IZT

100

ZZK @ IZK

600

500

480

400

150

100

150

170

200

225

250

1.0

R8 (3-February 2010)
