CMPZDC4V7 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> CMPZDC4V7

Preview

CMPZDC4V7: Description36 V, 0.35 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE; CategoryDiscrete semiconductor diode; File Size404KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMPZDC4V7 Overview

36 V, 0.35 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE

CMPZDC4V7 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Parts packaging code	SOT-23
package instruction	R-PDSO-G3
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	80 Ω
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	2
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.35 W
Certification status	Not Qualified
Nominal reference voltage	4.7 V
surface mount	YES
technology	ZENER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	6.38%
Working test current	5 mA

Preview

Download Datasheet

View All

CMPZDC2V4 THRU CMPZDC47V

SURFACE MOUNT

DUAL, COMMON CATHODE

SILICON ZENER DIODES

2.4 VOLTS THRU 47 VOLTS

350mW

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMPZDC2V4

Series silicon dual zener diode is a highly quality

voltage regulator, connected in a common cathode

configuration, for use in industrial, commercial,

entertainment and computer applications.

MARKING CODE: SEE MARKING CODES ON

ELECTRICAL CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Temperature

Thermal Resistance

SYMBOL

PD

TJ, Tstg

Θ

JA

350

-65 TO +150

357

UNITS

mW

°C

°C/W

ELECTRICAL CHARACTERISTICS:

(TA=25°C) VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

V

CMPZDC2V4

CMPZDC2V7

CMPZDC3V0

CMPZDC3V3

CMPZDC3V6

CMPZDC3V9

CMPZDC4V3

CMPZDC4V7

CMPZDC5V1

CMPZDC5V6

CMPZDC6V2

CMPZDC6V8

CMPZDC7V5

CMPZDC8V2

CMPZDC9V1

CMPZDC10V

CMPZDC11V

CMPZDC12V

CMPZDC13V

CMPZDC15V

CMPZDC16V

CMPZDC18V

CMPZDC20V

CMPZDC22V

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.5

7.0

7.7

8.5

9.4

10.4

11.4

12.4

13.8

15.3

16.8

18.8

20.8

MAX

V

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

11.6

12.7

14.1

15.6

17.1

19.1

21.2

23.3

TEST

CURRENT

MAXIMUM

ZENER IMPEDANCE

MAXIMUM

REVERSE

CURRENT

IR @

μA

50

20

10

5.0

2.0

1.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

0.1

0.05

VR

V

1.0

2.0

4.0

5.0

6.0

7.0

8.0

10.5

11.2

12.6

14.0

15.4

MAXIMUM

ZENER

VOLTAGE

CURRENT

TEMP.

COEFF.

IZM

mA

63

57

54

47

45

43

40

38

35

32

28

25

23

21

18

16

15

13

12

11

10

9.2

8.3

7.6

ΘV

Z

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

0.08

0.09

CCW3

CCW4

CCW5

CCW6

CCW7

CCW8

CCW9

CCZ1

CCZ2

CCZ3

CCZ4

CCZ5

CCZ6

CCZ7

CCZ8

CCZ9

CCY1

CCY2

CCY3

CCY4

CCY5

CCY6

CCY7

CCY8

TYPE

MARKING

CODE

IZT

mA

5.0

ZZT @ IZT

Ω

100

95

90

80

60

40

10

15

20

25

30

40

45

55

ZZK @ IZK

Ω

mA

600

500

480

400

150

80

100

150

170

200

225

250

1.0

R1 (3-February 2010)
