05001
Only One Name Means ProTek’Tion™
DA05N - DA24CP
HigH PoweReD multi-liNe tvs ARRAy
DesCRiPtioN
The DA16 Series are high powered multi-line TVS arrays available in a 16 pin DIP package. This series is designed to
protect monitoring and industrial equipment from the damaging effects of ESD, EFT and secondary transient threats.
The DA16 Series has a peak pulse power rating of 800 Watts for an 8/20µs waveshape. This devices meets the IEC
61000-4-2, IEC 61000-4-4 and IEC 61000-4-5 requirements.
16 PiN DiP PACkAge
FeAtuRes
• Compatible with IEC 61000-4-2 (ESD): Air - 15kV, Contact - 8kV
• Compatible with IEC 61000-4-4 (EFT): 40A - 5/50ns
• Compatible with IEC 61000-4-5 (Surge): 24A, 8/20µs - Level 2(Line-
Gnd) & Level 3(Line-Line)
• 800 Watts Peak Pulse Power per Line (tp = 8/20µs)
• Unidirectional & Bidirectional Configurations
• ESD Protection > 25 kilovolts
• Available in Multiple Voltages
• Protects 8 to 12 Lines
• RoHS Compliant
• REACH Compliant
APPliCAtioNs
•
•
•
•
•
Low Frequency I/O Ports
RS-232 & RS-423 Data Lines
Power Bus Lines
Monitoring & Industrial Signal & Data Ports
Microprocessor Based Equipment
meCHANiCAl CHARACteRistiCs
Molded 16 Pin Dual-In-Line (DIP) Package
Approximate Weight: 1.2 grams
Lead-Free Pure-Tin Plating (Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
• Flammability Rating UL 94V-0
•
•
•
•
PiN CoNFiguRAtioNs
UNIDIRECTIONAL
DAxxN Series
16
15
14
13
12
11
10
9
16
15
14
BIDIRECTIONAL
DAxxCN Series
13
12
11
10
9
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
DAxxP Series
16
15
14
13
12
11
10
9
16
15
14
DAxxCP Series
13
12
11
10
9
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
05001.R10 11/10
Page 1
www.protekdevices.com
05001
Only One Name Means ProTek’Tion™
DA05N - DA24CP
tyPiCAl DeviCe CHARACteRistiCs
mAXimum RAtiNgs
@ 25°C unless otherwise specified
PARAmeteR
Peak Pulse Power (tp = 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
Forward Surge Rating
symBol
P
PP
T
L
T
STG
I
F
vAlue
800
-55 to 150
-55 to 150
10
uNits
Watts
°C
°C
Amps
eleCtRiCAl CHARACteRistiCs PeR liNe
@ 25°C unless otherwise specified
PARt
NumBeR
(Note 1)
RAteD
stAND-oFF
voltAge
miNimum
BReAkDowN
voltAge
@1mA
v
(BR)
volts
6.0
6.0
6.0
6.0
13.3
13.3
13.3
13.3
16.7
16.7
16.7
16.7
26.7
26.7
26.7
26.7
mAXimum
ClAmPiNg
voltAge
(Fig. 2)
@ iP = 10A
v
C
volts
12.5
12.5
12.5
12.5
26.0
26.0
26.0
26.0
33.0
33.0
33.0
33.0
52.1
52.1
52.1
52.1
mAXimum
ClAmPiNg
voltAge
(Fig. 2)
@ 8/20µs
v
C
@ i
PP
24.6V @ 45.0A
24.6V @ 45.0A
24.6V @ 45.0A
24.6V @ 45.0A
32.9V @ 34.0A
32.9V @ 34.0A
32.9V @ 34.0A
32.9V @ 34.0A
37.7V @ 27.0A
37.7V @ 27.0A
37.7V @ 27.0A
37.7V @ 27.0A
53.0V @ 20.0A
53.0V @ 20.0A
53.0V @ 20.0A
53.0V @ 20.0A
mAXimum
leAkAge
CuRReNt
@v
wm
i
D
µA
200
200
200
200
2
2
2
2
2
2
2
2
2
2
2
2
tyPiCAl
CAPACitANCe
v
wm
volts
DA05N
DA05P
DA05CN
DA05CP
DA12N
DA12P
DA12CN
DA12CP
DA15N
DA15P
DA15CN
DA15CP
DA24N
DA24P
DA24CN
DA24CP
Notes
5.0
5.0
5.0
5.0
12.0
12.0
12.0
12.0
15.0
15.0
15.0
15.0
24.0
24.0
24.0
24.0
@0v, 1mHz
C
pF
880
880
500
500
440
440
385
385
400
400
300
300
275
275
200
200
1. The “C” suffix denotes a bidirectional device, such as DA05CN.
05001.R10 11/10
Page 2
www.protekdevices.com
05001
Only One Name Means ProTek’Tion™
DA05N - DA24CP
tyPiCAl DeviCe CHARACteRistiCs
FiguRe 1
PeAk Pulse PoweR vs Pulse time
100
P
PP
- Peak Pulse Power - kilowatts
10
800W, 8/20µs Waveform
1
0.1
0.1
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
120
i
PP
- Peak Pulse Current - % of i
PP
FiguRe 2
Pulse wAve FoRm
t
f
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
100
80
% of Rated Power
FiguRe 3
PoweR DeRAtiNg CuRve
Peak Pulse Power
8/20µs
100
80
60
40
20
0
0
5
e
-t
60
40
20
0
Average Power
t
d
= t/(I
PP
/2)
10
15
t - time - µs
20
25
30
0
25
50
75 100 125
t
A
- Ambient temperature - °C
150
05001.R10 11/10
Page 3
www.protekdevices.com
05001
Only One Name Means ProTek’Tion™
DA05N - DA24CP
16 PiN DiP PACkAge iNFoRmAtioN
outliNe DimeNsioNs
Dim
A
B
C
D
E
F
G
H
I
J
K
L
Notes
A
millimeteRs
miN
18.80
6.35
7.50
0.21
0°
0.51
3.69
2.80
1.02
1.27
0.39
2.54
iNCHes
miN
0.740
0.250
0.295
0.008
0°
0.020
0.145
0.110
0.040
0.050
0.015
0.100
mAX
19.55
6.85
7.74
0.38
10°
1.01
4.44
3.30
1.77
1.27
0.53
2.54
mAX
0.770
0.270
0.305
0.015
10°
0.040
0.175
0.130
0.070
0.050
0.021
0.100
D
16 Places
E
G
H
L
J
12 Places
K
16 Places
B
C
I
12 Places
F
Orientation
Dot
(Pin #1)
1. Dimensions are exclusive of mold flash and metal burrs.
2. Dimensions “J” and “L” are between centers.
oRDeRiNg iNFoRmAtioN
BAse PARt NumBeR
(xx = voltage)
DAxxN
DAxxP
DAxxCN
DAxxCP
Notes
leADFRee suFFiX
-LF
-LF
-LF
-LF
tAPe suFFiX
n/a
n/a
n/a
n/a
Qty/Reel
n/a
n/a
n/a
n/a
Reel siZe
n/a
n/a
n/a
n/a
tuBe Qty
25
25
25
25
1. Marking on Part - logo, part number, date code and pin one defined by dot on top of package.
Package outline per document number 06003.R2 9/09.
05001.R10 11/10
Page 4
www.protekdevices.com
05001
Only One Name Means ProTek’Tion™
DA05N - DA24CP
ComPANy iNFoRmAtioN
ComPANy PRoFile
ProTek Devices, based in Tempe, Arizona USA, is a manufacturer of Transient Voltage Suppression (TVS) products designed specifically for
the protection of electronic systems from the effects of lightning, Electrostatic Discharge (ESD), Nuclear Electromagnetic Pulse (NEMP), in-
ductive switching and EMI/RFI. With over 25 years of engineering and manufacturing experience, ProTek designs TVS devices that provide
application specific protection solutions for all electronic equipment/systems.
ProTek Devices Analog Products Division, also manufactures analog interface, control, RF and power management products.
CoNtACt us
Corporate Headquarters
2929 South Fair Lane
Tempe, Arizona 85282
USA
By telephone
General: 602-431-8101
Sales: 602-414-5109
Customer Service: 602-414-5114
By Fax
General: 602-431-2288
By e-mail:
Sales: sales@protekdevices.com
Customer Service: service@protekdevices.com
Technical Support: support@protekdevices.com
web
www.protekdevices.com
www.protekanalog.com
COPYRIGHT © ProTek Devices 1998 - This literature is subject to all applicable copyright laws and is not for resale in any manner.
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice.
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice and that the final judgement concerning selection and specifications is the buyer’s and that in furnishing engineering
and technical assistance. ProTek assumes no responsibility with respect to the selection or specifications of such products. ProTek makes no warranty, representation or guarantee regarding the suitability of
its products for any particular purpose, nor does ProTek assume any liability arising out of the application or use of any product or circuit and specifically disclaims any and all liability without limitation special,
consequential or incidental damages.
LIFE SUPPORT POLICY: ProTek Devices products are not authorized for use in life support systems without written consent from the factory.
