CZS5064

SURFACE MOUNT

SILICON CONTROLLED RECTIFIER

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CZS5064 type is

an epoxy molded PNPN Silicon Controlled Rectifier

manufactured in an epoxy molded surface mount

package, designed for control systems and sensing

circuit applications.

MARKING: FULL PART NUMBER

SOT-223 CASE

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Peak Repetitive Off-State Voltage

Peak Repetitive Reverse Voltage

RMS On-State Current

Average On-State Current (TC=67°C)

Operating Junction Temperature

Storage Temperature

Thermal Resistance

SYMBOL

VDRM

VRRM

IT(RMS)

IT(AV)

Tstg

400

0.8

0.51

-40 to +125

-40 to +150

150

UNITS

°C

°C/W

ELECTRICAL CHARACTERISTICS:

(TA=25°C unless otherwise noted)

SYMBOL

TEST CONDITIONS

MIN

IDRM

VD=400V, RGK=1.0KΩ, TC=125°C

IRRM

IGT

VGT

VGD

tON

VD=400V, RGK=1.0KΩ, TC=125°C

IT=1.2A

VD=7.0V, RL=100Ω, RGK=1.0KΩ

VD=400V, RL=100Ω, TC=125°C

VD=7.0, RGK=1.0KΩ

VD=400V, IGT=1.0mA, IF=1.0A,

RGK=1KΩ, di/dt=6.0A/μs

0.1

TYP

MAX

1.7

200

0.8

5.0

UNITS

μA

μs

2.8

R4 (23-February 2010)
