SAF-XE162HM-24FXXL datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAF-XE162HM-24FXXL

SAF-XE162HM-24FXXL: DescriptionRISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size865KB，102 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

SAF-XE162HM-24FXXL Overview

RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64

SAF-XE162HM-24FXXL Parametric

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	0.50 MM PITCH, GREEN, PLASTIC, LQFP-64
Contacts	64
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Has ADC	YES
Address bus width
bit size	16
maximum clock frequency	40 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G64
length	10 mm
Number of I/O lines	40
Number of terminals	64
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Package shape	SQUARE
Package form	FLATPACK
Certification status	Not Qualified
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	80 MHz
Maximum supply voltage	1.6 V
Minimum supply voltage	1.4 V
Nominal supply voltage	1.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC

Preview

Download Datasheet

View All

16-Bit

Architecture

XE162FM, XE162HM

16-Bit Single-Chip

Real Time Signal Controller

XE166 Family Derivatives / Base Line

Data Sheet

V2.0 2009-03

M ic r o co n t ro l l e r s

XE162FM, XE162HM

XE166 Family Derivatives / Base Line

Table of Contents

2.1

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

3.15

3.16

3.17

3.18

4.1

4.2

4.2.1

4.2.2

4.2.3

4.3

4.4

4.5

4.6

4.6.1

4.6.2

4.6.3

4.6.4

4.6.5

4.6.6

Data Sheet

Summary of Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

General Device Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Pin Configuration and Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Subsystem and Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Protection Unit (MPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Checker Module (MCHK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-Chip Debug Support (OCDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare Unit (CAPCOM2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare Units CCU6x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Purpose Timer (GPT12E) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .

Real Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A/D Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Universal Serial Interface Channel Modules (USIC) . . . . . . . . . . . . . . . . .

MultiCAN Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clock Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical Parameters

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters for Upper Voltage Area . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters for Lower Voltage Area . . . . . . . . . . . . . . . . . . . . . . . .

Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Analog/Digital Converter Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Flash Memory Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Testing Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Definition of Internal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Clock Input Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pad Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Synchronous Serial Interface Timing . . . . . . . . . . . . . . . . . . . . . . . . . . .

Debug Interface Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package and Reliability

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

V2.0, 2009-03

SAF-XE162HM-24FXXL Related Products

	SAF-XE162HM-24FXXL	SAF-XE162FM-48FXXL	SAF-XE162FM-24FXXL	SAF-XE162FM-72FXXL	SAF-XE162HM-48FXXL
Description	RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	RISC Microcontroller, 16-Bit, FLASH, 80MHz, CMOS, PQFP64, 0.50 MM PITCH, GREEN, PLASTIC, LQFP-64
Parts packaging code	QFP	QFP	QFP	QFP	QFP
package instruction	0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	0.50 MM PITCH, GREEN, PLASTIC, LQFP-64	LFQFP,	0.50 MM PITCH, GREEN, PLASTIC, LQFP-64
Contacts	64	64	64	64	64
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant
ECCN code	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2
Has ADC	YES	YES	YES	YES	YES
bit size	16	16	16	16	16
maximum clock frequency	40 MHz	40 MHz	40 MHz	40 MHz	40 MHz
DAC channel	NO	NO	NO	NO	NO
DMA channel	NO	NO	NO	NO	NO
JESD-30 code	S-PQFP-G64	S-PQFP-G64	S-PQFP-G64	S-PQFP-G64	S-PQFP-G64
length	10 mm	10 mm	10 mm	10 mm	10 mm
Number of I/O lines	40	40	40	40	40
Number of terminals	64	64	64	64	64
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	LFQFP	LFQFP	LFQFP	LFQFP
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	FLATPACK	FLATPACK	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
ROM programmability	FLASH	FLASH	FLASH	FLASH	FLASH
Maximum seat height	1.6 mm	1.6 mm	1.6 mm	1.6 mm	1.6 mm
speed	80 MHz	80 MHz	80 MHz	80 MHz	80 MHz
Maximum supply voltage	1.6 V	1.6 V	1.6 V	1.6 V	1.6 V
Minimum supply voltage	1.4 V	1.4 V	1.4 V	1.4 V	1.4 V
Nominal supply voltage	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V
surface mount	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.5 mm	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD
width	10 mm	10 mm	10 mm	10 mm	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC
Maker	Infineon	Infineon	-	Infineon	Infineon
