REVISION M
DO NOT
SCALE FROM
THIS PRINT
.100 2.54
REF
02
C
.300 7.62
REF
C
"A" REF
(SEE TABLE 1)
C
"B"
+.006
- .004
(SEE TABLE 1)
.178 4.51
REF
C
"A"
01
"A"
C
.0787 2.000
L
EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX
No OF POSITIONS
-05 THRU -25
LEAD STYLE
-01
OPTION 3
-TR: TAPE & REEL
OPTION 2
-P: PICK & PLACE PAD
(FOR -SM ONLY, USE PPP-24)
(USE PPP-55 WITH -SM-TR OPTION)
(SEE SHT 3, FIG 5)
(NOT AVAILABLE WITH -LC)
-K: POLYIMIDE FILM PAD
(SEE SHT 2, FIG 4)
(NOT AVAILABLE WITH -LC)
(FOR -SM ONLY)
POLARIZATION OPTION
-XX= PIN OMITTED
OPTION 1
-LC: LOCKING CLIP(SEE NOTE 8)
(FOR -SM ONLY, SEE NOTE 8)
(NOT AVAILABLE WITH -P OR -K)
-SR STRAIN RELIEF
TAIL OPTION
-RA: RIGHT ANGLE
-SM: SURFACE MOUNT
(LEAVE BLANK FOR THRU HOLE)
.020 0.51
REF
2 MAX SWAY
(EITHER DIRECTION)
"C" REF
(SEE TABLE 1)
EHA-06
C
.020 0.50 SQ
REF (TYP)
PLATING SPECIFICATION
-S: 30µ" SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAIL.
-F: 3µ" SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAIL.
-T: 200µ" MATTE TIN ON ENTIRE CONTACT.
-H: 30µ" SELECTIVE GOLD IN CONTACT
AREA, 3µ" SELECTIVE GOLD ON TAIL.
-L: 15µ" SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAIL.
ROW SPECIFICATION
-D: DOUBLE
EHH-XX-D-SR
C
.593 15.07
REF
.370 9.40
C
REF
.120 3.05 REF
90°
.004[0.10]
T-1S13-05-XXX-2
SECTION "A"-"A"
LC-09-TM
.060 1.52
C
.005 0.12
C
(SEE NOTE 7)
(EHT-105-01-XX-D-SM-SR-LC SHOWN)
.093 2.35 REF
C
L
POS 1 INDICATOR
NOTES:
FIG 1
C
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. COPLANARITY TO BE WITHIN .004[0.10].
C
"E" REF
3. BURR ALLOWANCE: .0015[0.038] MAX.
(SEE TABLE 1)
4. MINIMUM PUSHOUT FORCE: .5 LB. [2.22N]
5. MAXIMUM ALLOWABLE BOW: .002[0.05]
INCH/INCH AFTER ASSEMBLY.
6. MAXIMUM PIN ROTATION IN BODY: 2°
7. MEASURE AT BEND
8.DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED,
THE –LC OPTION IS NOT COMPATIBLE WITH AUTO PLACEMENT.
SAMTEC RECOMMENDS MANUAL PLACEMENT FOR ALL ASSEMBLIES WITH THE –LC OPTION.
F:\DWG\MISC\MKTG\EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX-MKT.SLDDRW
"D"
(SEE TABLE 1)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
.XX: .01 [0.3]
2
.XXX: .005 [0.13]
.XXXX: .0020 [0.051]
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
INSULATOR: VECTRA E130, COLOR: NATURAL
TERMINAL: PHOS BRONZE
MAX FLASH ALLOWED: .002[0.05]
MAX GATE VESTIGE: .002[0.05]
DO NOT SCALE DRAWING
SHEET SCALE: 5:2
EHT EJECTOR HEADER ASSEMBLY
EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX
08/04/2008
SHEET
1
OF
3
BY:
CHADP
REVISION M
"B"
C
"D"
2 MAX SWAY
C
(EITHER DIRECTION)
T-1S13-05-XXX-2
"C"
.397 10.08
C
C
.114 2.90
C
"F"
- .004
(SEE TABLE 1)
+.006
"B"
.0787 2.000
C
.120 3.05 REF
T-1S13-15-
XXX-2
T-1S13-06-XXX-2
.0787±.0050 2.000±0.127
C
2 MAX SWAY
(EITHER DIRECTION)
(EHT-105-01-XX-D-SR SHOWN )
(SAME AS FIG 1 DIFFERENT AS SHOWN)
PT-1-24-03-60
TP-13
PT-1-24-03-60
TP-13
FIG 2
SECTION "B"-"B"
"C"
(EHT-105-01-XX-D-RA-SR SHOWN)
(SAME AS FIG 1 DIFFERENT AS SHOWN)
90°±3°
C
(TYP)
FIG 3
SECTION "C"-"C"
PT-1-24-02-74
TP-13
.555 14.10
C
.272 6.91
.120 3.06 REF
C
.714 18.14
C
.060±.010 1.52±0.25
.431 10.95
-RA IN-PROCESS 1
FILL BODY WITH PIN
"H"
(SEE NOTE)
-RA IN-PROCESS 2
BEND TAIL
.2953±.0050 7.501±0.127
.018±.020 0.45±0.51
-RA IN-PROCESS 3
BEND TAILS
THRU HOLE OPTION
-SM OPTION
PACKAGING VIEWS
-RA OPTION
(LOAD PARTS WITH POSITION #1 INDICATOR
IN SAME DIRECTION AS ARROW ON TUBE)
"G" (SEE NOTE)
-K: OPTION (POLYIMIDE FILM PAD)
NOTE: "G" = USE MEASURED DIMENSION (REF)
(SAME AS FIG 1 DIFFERENT AS SHOWN)
"H" = {("G" -.2953[7.50]/2) ±.020[0.51]}
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
FIG 4
*
PROPRIETARY NOTE
*
C
.397 10.08
90° (TYP)
.190
+.000
- .005
4.84
-0.000
0.127
C
C
.004[0.01]
.350±.010 8.89±0.254
C
.081 2.05
-SM IN-PROCESS 2
BEND TAILS
F:\DWG\MISC\MKTG\EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX-MKT.SLDDRW
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
-SM IN-PROCESS 1
FILL BODY WITH PINS
DO NOT SCALE DRAWING
SHEET SCALE: 1.75:1
EHT EJECTOR HEADER ASSEMBLY
EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX
08/04/2008
SHEET
2
OF
3
BY:
CHADP
REVISION M
.325 8.26
REF
.237 6.03
REF
"H"
(SEE NOTE)
"G" (SEE NOTE)
PPP-24
IN-PROCESS
ARM ASSEMBLY & ROTATION
.338 8.59
(LATCH EHA-01 REMOVED FOR CLARITY)
-PPP: PICK AND PLACE PAD
(SAME AS FIG 1 DIFFERENT AS SHOWN)
.136 3.44 REF
NOTE: "G" = USE MEASURED DIMENSION (REF)
"H" = {("G" -.325[8.26]/2) ±.020[0.51]}
FIG 5
OPEN LATCH VIEW
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
EHT EJECTOR HEADER ASSEMBLY
EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX
08/04/2008
SHEET
3
OF
3
F:\DWG\MISC\MKTG\EHT-1XX-01-X-D-XX-SR-XX-XX-X-XX-MKT.SLDDRW
BY:
CHADP
