E-Series Surface Mount Mixer
1 - 500 MHz
Features
q
q
q
ESCM-1
V3.00
SM-3
LO Power: +7 dBm
Up to +1 dBm RF
Surface Mount
Specifications
@ 25°C
Frequency Range
RF
LO
IF
Conversion Loss (dB)
2 - 250 MHz
1 - 500 MHz
Isolation (dB)
LO to RF
1 - 10 MHz
10 - 250 MHz
250 - 500 MHz
LO to IF
1 - 10 MHz
10 - 250 MHz
250 - 500 MHz
Typical
6.0
6.5
Typical
60
45
40
55
45
40
1 - 500 MHz
1 - 500 MHz
DC - 500 MHz
Maximum
7.0
8.0
Minimum
40
35
30
40
35
25
SM-26
Operating Characteristics
Impedance
RF input for 1dB Compression
50 Ohms Nominal
+1 dBm
Ordering Information
Part No.
ESCM-1
ESCM-1/SM-3
ESCM-1/SM-3TR
Packaging
SM-26 in Tubes
SM-3 in Tubes
SM-3 Forward Tape & Reel
Absolute Maximum Ratings
Parameter
RF Power
Peak IF Current
Storage Temperature
Operating Temperature
Pin Temperature (10 Seconds)
Absolute Maximum
50 mW
40 mA
-55°C to 100°C
-55°C to 100°C
260°C
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .x = ±0.04 (1.00)
.xx = ±0.02 (0.50)
.xxx = ±0.010 (0.250)
Pin Configuration
Function
LO
RF
IF*
Ground
* IF pins must be connected together externally.
S 0140 D
Pin No.
8
1
3,4
2,5,6,7
Specifications Subject to Change Without Notice.
M/A-COM, Inc.
North America:
Tel. (800) 366-2266
Fax (800) 618-8883
s
1
Asia/Pacific: Tel. +81 (03) 3226-1671
Fax +81 (03) 3226-1451
s
Europe: Tel. +44 (1344) 869 595
Fax +44 (1344) 300 020
