REMEC
Triple Balanced Mixer
Ultra-Broadband
Electrical Specifications
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
RF to IF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(1)
RF 2.0-18.0 GHz
LO 2.0-18.0 GHz
IF 10-4000 MHz
:
Conditions
RF(GHz)
2.0-18.0
LO(GHz)
2.0-18.0
2.0-4.0
4.0-18.0
2.0-18.0
2.0-18.0
2.0-18.0
2.0-18.0
10-4000
IF(MHz)
10-4000
Min
Specifications
Typical
7.3 dB
20 dB
27 dB
28 dB
22 dB
+5 dBm
+8 dBm
+12 dBm
+15 dBm
+14 dBm
+17 dBm
+21 dBm
+24 dBm
+10 dBm
+13 dBm
+17 dBm
+21 dBm
Max
9.5 dB
MM9xxL-1
LO Power
4 = +10 dBm
6 = +13 dBm
7 = +17 dBm
8 = +21 dBm
15 dB
20 dB
20 dB
2.0-18.0
2.0-18.0
10-4000
(4)
2.0-18.0
2.0-18.0
10-4000
MM94
MM96
MM97
MM98
MM94
MM96
MM97
MM98
MM94
MM96
MM97
MM98
Drop-In Module or
With SMA(F)
Connectors
M = Module
P = With Connectors
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system from -55°C to +100°C
with the nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss.
3. Conversion loss typically degrades less than 0.5 dB at +100°C and improves less than 0.5 dB at -55°C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
Typical
Performance
at 25°C
MM9xxL-1
Outline: L1
All dimensions are in inches and [mm].
Specifications subject to change without notice.
