Series 171 MicroStrips
Single Row Strips with Solder Cups
171-001
Micro-D
Latching
MicroStri ps
171-001-7PS-P1CL
Single Row Solder Cup MicroStrips
These .050" pitch single row solder cup microstrips accept #26 to #30 gage
wire with standard contacts and up to size #24 wire with "large bore" contacts.
Contacts are factory-installed and potted. Available with 1 to 30 contacts. Optional
stainless steel latching mechanism prevents de-mating. Guide pins provide circuit
polarization. Contacts are twistpin type and are gold-plated. Housing is molded
LCP thermoplastic. Suitable for high-reliability applications where long-term
resistance to fretting corrosion is a necessity. 3 A., 600 Vac, -55C to +150C.
How To Order Solder Cup Microstrips
Series
Number of
Cavities
Contact Gender
and Solder Cup
Size
Pin Contacts, Size
#26 Solder Cup
Optional
Guide
Pin
For No Guide Pin
Optional
Latch
Optional
Mounting
Holes
For No Mounting
Holes
Mounting Holes
Single Row
MicroStrip, .050"
Contact Spacing,
Solder Cup Contacts
171-001
Total number of
cavities including
guide pins,latches
and mounting
holes.
The number of
cavities equals the
number of electrical
circuits plus 1
cavity for each
guide pin and latch,
plus 6 cavities for
the mounting hole
option.
-1
to
-30
PS
Omit
-P1
For No Latch
Omit
CL
Omit
MH
Guide Pin in Cav. #1
Center Latch
Pin Contacts, Size
#24 Solder Cup
Guide Pin at Both
Ends
NS
-PB
Latch at Both Ends
BL
Socket Contacts,
Size #26 Solder Cup
SS
The three cavities
on each end are
filled with epoxy.
Two .062" (1.57mm)
holes are cross-
drilled to allow for
attachment to a
mounting surface.
Replace (X) with
guide pin location.
P3 shown below:
-P(X)
Socket Contacts,
Size #24 Solder Cup
TS
Sample Part Number
171-001
-7
PS
- P1
CL
Q
© 2011 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Q-4
171-001
PIN CONNECTOR
.200 (5.08) MAX
.075
(1.91)
TYP
.300 (7.62)
2Xø.062 (1.57)
C
.110 (2.79)
MAX
.125 (3.18)
.135/.116
(3.43/2.95)
.075 (1.91)
MAX
.062 (1.57)
.200 (5.08) REF
.075 (1.91)
.050 (1.27)
MAX
SOCKET CONNECTOR
2Xø.062
(1.57)
.050 (1.27)
MAX
.075 (1.91) TYP
C
.200 (5.08)
MAX
.125 (3.18)
.075 (1.91)
.075 (1.91)
(A)
B
(A)
B
Dimensions
# of
Cavities
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
(A)
In.
-
.050
.100
.150
.200
.250
.300
.350
.400
.450
.500
.550
.600
.650
.700
B Max.
mm.
In.
.085
.135
.185
.235
.285
.335
.385
.435
.485
.535
.585
.635
.685
.735
.785
C
In.
N/A
N/A
N/A
N/A
N/A
N/A
.200
.250
.300
.350
.400
.450
.500
.550
.600
mm.
2.16
3.43
4.70
5.97
7.24
8.51
9.78
11.05
12.32
13.59
14.86
16.13
17.40
18.67
19.94
mm.
N/A
N/A
N/A
N/A
N/A
N/A
5.08
6.35
7.62
8.89
10.16
11.43
12.7
13.97
15.24
-
1.27
2.54
3.81
5.08
6.35
7.62
8.89
10.16
11.43
12.70
13.97
15.24
16.51
17.78
# of
Cavities
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
(A)
In.
.750
.800
.850
.900
.950
1.000
1.050
1.100
1.150
1.200
1.250
1.300
1.350
1.400
1.450
B Max.
mm.
In.
.835
.885
.935
.985
1.035
1.085
1.135
1.185
1.235
1.285
1.335
1.385
1.435
1.485
1.535
C
In.
.650
.700
.750
.800
.850
.900
.950
1.000
1.050
1.100
1.150
1.200
1.250
1.300
1.350
mm.
21.21
22.48
23.75
25.02
26.29
27.56
28.83
30.10
31.37
32.64
33.91
35.18
36.45
37.72
38.99
mm.
16.51
17.78
19.05
20.32
21.59
22.86
24.13
25.4
26.67
27.94
29.21
30.48
31.75
33.02
34.29
19.05
20.32
21.59
22.86
24.13
25.40
26.67
27.94
29.21
30.48
31.75
33.02
34.29
35.56
36.83
Center Latch Locations
Even Number of Cavities
PIN CONNECTOR SOCKET CONNECTOR
Odd Number of Cavities
PIN CONNECTOR SOCKET CONNECTOR
CAVITY 1
CAVITY 1
CAVITY 1
CAVITY 1
Latch placed on next lower cavity prior to centerline.
Latch position = (# of Cavities) ÷ 2.
Latch placed in cavity on centerline.
Latch Position = (# of Cavities+1) ÷ 2.
© 2011 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Q-5
Micro-D
Series 171 MicroStrips
Single Row Solder Cup Strips
Q
