esignator
le Below)
5B
Bayonet Coupling Narrow Flange Mount Receptacle
MS3440 Type
Connector
Style
016
= Hermetic Narrow Flange
Mount Receptacle
Alternate Insert
Arrangement
W, X, Y or Z
(Omit for Normal)
230-016
MIL-DTL-26482 Series II Type Hermetic
e
ticity Mod Code
E MOD CODES
Series 230
ed Leak Rate
MIL-DTL-26482
Type
s Helium per second
s Helium per second
s Helium per second
TION CODES
ng Plus Outgassing
cessing
Thermal vacuum
Outgassing
24 hrs. 125° C.
A
F
E
D
B
C
MIL-DTL
26482
Type
Insert
Arrangement
Per MIL-STD-1669
230
-
016
FT
10
-
6
Shell
Size
P
X
HERMETIC LEAK RATE MOD CODES
Designator
–585A
–585B
–585C
Material/Finish
Z1
= Stainless Steel/
Passivated
FT
= C1215 Stainless
Steel/Tin Plated
(See Note 2)
Contact Type
P
= Solder Cup, Pin Face
X
= Eyelet, Pin Face
Required Leak Rate
1 x 10
-10
cc’s Helium per second
1 x 10
-9
cc’s Helium per second
1 x 10
-8
cc’s Helium per second
D
.060 Width
Polarizing
Stripe
Master
Polarizing
Keyway
Min Edge Distance
Relative To Mounting Holes
Shell Sizes 8 - 18 = .035
Shell Sizes 20 - 24 = .050
Peripheral
Gasket
L Max
Ref
F
G
Vitreous
Insert
Contact
Style "P"
D
Min
C
Contact
Style "X"
Mod 429C
B
Typ
Mod 429A
Mod 186M
Ø H Typ
Interfacial
Seal
Painted
Bayonet
Pins 3 Pl
P (Size 20 Contacts)
V (Size 16 & 12 Contacts)
J
4 Pl
A Max
(Typ)
APPLICATION NOTES
1.
2.
To be identified with manufacturer’s name, part number and
date code, space permitting.
Material/Finish:
Shell: Z1 - 304L
stainless steel/passivate.
FT - C1215
stainless steel/tin plated.
Titanium and Inconel
®
available. Consult factory.
Contacts - 52 Nickel alloy/gold plate.
Bayonets - Stainless steel/passivate.
Seals - Silicone elastomer/N.A.
Insulation - Glass/N.A.
Consult factory and/or MIL-STD-1669 for arrangement and
insert position options.
4.
Glenair 230-016 will mate with any QPL MIL-DTL-26482
Series II bayonet coupling plug of same size and insert
polarization.
Performance:
Hermeticity - <1 x 10
-7
cc/sec @ 1 atmosphere
differential.
Dielectric withstanding voltage - Consult factory
or MIL-STD-1669.
Insulation resistance - 5000 megohms min @500VDC.
Metric Dimensions (mm) are indicated in parentheses.
5.
3.
6.
© 2009 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
D-14
Bayonet Coupling Narrow Flange Mount Receptacle
MS3440 Type
TABLE I: CONNECTOR AND CUT-OUT DIMENSIONS (Continued Below)
Shell
Size
8
10
12
14
16
18
20
22
24
A
.828 (21.03)
.954 (24.2)
1.047 (26.6)
1.141 (29.0)
1.234 (31.3)
B
.594 (15.1)
.719 (18.3)
.812 (20.6)
.906 (23.0)
.969 (24.6)
C Dia
Mounting
Locator
.563/.557
(14.3/14.1)
.673/.667
(17.1/16.9)
.782/.776
(19.9/19.7)
.907/.901
(23.0/22.9)
1.032/1.026
(26.2/26.1)
1.157/1.151
(29.4/29.2)
1.251/1.245
(31.8/31.6)
1.376/1.371
(35.0/34.8)
1.501/1.495
(38.1/38.0)
D Dia
Min
.403 (10.2)
.515 (13.1)
.630 (16.0)
.755 (19.2)
.880 (22.4)
.980 (24.9)
1.105 (28.1)
1.230 (31.2)
1.385 (35.2)
F
.598/.578
(15.2/14.7)
.598/.578
(15.2/14.7)
.598/.578
(15.2/14.7)
.598/.578
(15.2/14.7)
.598/.578
(15.2/14.7)
.598/.578
(15.2/14.7)
.660/.640
(16.8/16.3)
.660/.640
(16.8/16.3)
.660/.640
(16.8/16.3)
G
.078/.04
(2.0/1.0)
.078/.04
(2.0/1.0)
.078/.04
(2.0/1.0)
.078/.04
(2.0/1.0)
.078/.04
(2.0/1.0)
.078/.04
(2.0/1.0)
.110/.078
(2.8/2.0)
.110/.078
(2.8/2.0)
.110/.078
(2.8/2.0)
H
.120 (3.0)
.120 (3.0)
.120 (3.0)
.120 (3.0)
.120 (3.0)
.120 (3.0)
.120 (3.0)
.120 (3.0)
.147 (3.7)
1.328 (33.7) 1.062 (27.0)
1.453 (36.9) 1.156 (29.4)
1.578 (40.1)
1.250 (31.8)
1.703 (43.3) 1.375 (34.9)
TABLE I (Continued): CONNECTOR AND CUT-OUT DIMENSIONS
Shell
Size
8
10
12
14
16
18
20
22
24
J
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
.125/.105
(3.2/2.7)
L
.801 (20.3)
.801 (20.3)
.801 (20.3)
.801 (20.3)
.801 (20.3)
.801 (20.3)
.863 (21.9)
.895 (22.7)
.895 (22.7)
P
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.178/.118
(4.5/3.0)
.146/.086
(3.7/2.2)
.146/.086
(3.7/2.2)
v
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.248/.188
(6.3/4.8)
.216/.156
(5.5/4.0)
.216/.156
(5.5/4.0)
Panel
Cut-Out Dia
.570 (14.5)
.680 (17.3)
.789 (20.0)
.914 (23.2)
1.039 (26.4)
1.164 (29.6)
1.258 (32.0)
1.383 (35.1)
1.508 (38.3)
Max.
Weight
(Lbs)
.038
.044
.052
.070
.085
.098
.110
.150
.280
© 2009 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
D-15
MIL-DTL
230-016
MIL-DTL-26482 Series II Type Hermetic
D
