Extended Duty Electrical Pin Contact
D38999
M39029/107
850-007
A
AS39029
Ser. I, III, IV
M29600
Extended Duty Pin Crimp Contact for MIL-DTL-38999 Series I, III and IV Connectors
Mating End
Size
22
20
16
12
10
Wire
Accomodation
22-28 AWG
20-24 AWG
16-20 AWG
12-14 AWG
10 AWG
Military Part Number
M39029/107-620
M39029/107-621
M39029/107-622
M39029/107-623
M39029/107-624
Glenair Part Number
850-007-22-620
850-007-20-621
850-007-16-622
850-007-12-623
850-007-10-624
T (Ref)
Color Bands
2nd
1st
S
3rd
M
.033
.029
.300
.295
H x 45°
ØB
Ø F (Flat)
ØC
ØG
ØE
Manufacturer
Symbol
A Rad
Ø D Thru
One Side Only
K
S
.129
.122
.010 Typ
.004
Ø .041
.036
60°
Typ
-22-620 Only
.040
.030
ØG
ØU
-10-624 Only
V
Material and Finish
Copper alloy, plated with 5 μinches gold over 45 μinches palladium alloy.
Rated to 1500 cycles of durability.
© 2011 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-20
Extended Duty Electrical Pin Contact
M39029/107
850-007
TABLE I: CONTACT DIMENSIONS
Size
22
20
16
12
10
Part Number
850-007-22-620
850-007-20-621
850-007-16-622
850-007-12-623
850-007-10-624
Military Number
M39029/107-620
M39029/107-621
M39029/107-622
M39029/107-623
M39029/107-624
A Rad
.020
.010
.025
.015
.025
.020
.025
.020
.025
.020
øB
.0305
.0295
.041
.039
.0635
.0616
.095
.093
.126
.124
øC
.062
.060
.094
.091
.130
.127
.182
.179
.242
.238
øD
.022
.018
.032
.026
.042
.036
.042
.036
.052
.040
øE
.0355
.0335
.048
.046
.068
.066
.102
.098
.140
.134
øF
.011
max
.015
max
.030
.011
.062
.043
.094
.074
øG
.048
.046
.070
.068
.103
.101
.151
.148
.213
.207
H
.005
.003
.010
.005
.010
.005
.016
.005
.016
.005
A
TABLE I: (Continued) CONTACT DIMENSIONS
Size
22
20
16
12
10
Part Number
850-007-22-620
850-007-20-621
850-007-16-622
850-007-12-623
850-007-10-624
Military Number
M39029/107-620
M39029/107-621
M39029/107-622
M39029/107-623
M39029/107-624
K
.157
.141
.229
.209
.229
.209
.229
.209
.385
.355
M
–
.078
.072
.088
.082
.088
.082
.115
.108
S
.237
.231
.237
.231
.237
.231
.237
.231
.405
.395
T
(Ref)
.531
.531
.531
.531
.698
ØU
–
–
–
–
.183
.177
V
–
–
–
–
.121
.111
Color Bands
1st
Blue
Blue
Blue
Blue
Blue
2nd
Red
Blue
Red
Red
Red
3rd
Black
Brown
Red
Orange
Yellow
TABLE II: TOOL COMPATIBILITY
Size
22
Part Number
850-007-22-620
Military Number
M39029/107-620
AWG
Handling
22, 24, 26, 28
Crimp Tool
M22520/2-01
M22520/7-01
M22520/1-01
M22520/2-01
M22520/7-01
M22520/1-01
M22520/7-01
M22520/1-01
Daniels 1716P-1
Positioner
M22520/2-09
M22520/7-07
M22520/1-04 (red)
M22520/2-10
M22520/7-08
M22520/1-04 (blue)
M22520/7-04
M22520/1-04
(yellow)
Daniels 1716P-1
Insertion Tool
M81969/8-01
M81969/14-01
M81969/8-05
M81969/14-10
Extraction Tool
M81969/8-02
M81969/14-01
M81969/8-06
M81969/14-10
20
850-007-20-621
M39029/107-621
20, 22, 24
16
12
10
850-007-16-622
850-007-12-623
850-007-10-624
M39029/107-622
M39029/107-623
M39029/107-624
16, 18, 20
12, 14
10
M81969/8-07
M81969/14-03
M81969/8-09
M81969/14-04
M81969/14-05
and M81969/8-11
M81969/8-08
M81969/14-03
M81969/8-10
M81969/14-04
M81969/14-05 and
M81969/8-12
© 2011 Glenair, Inc.
www.glenair.com
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
E-Mail: sales@glenair.com
A-21
