Terminals
®
Nylon Insulated Fork Terminals
Catalog
Number
KN18-6F-M
KN18-8F-M
KN18-10F-M
KN18-14F-M
22-16
A.W.G.
0.5-1.5
mm
2
®
Wire
Range
Bolt
Size (d2)
#6
#8
#10
1/4
#6
.146
3.7
.169
4.3
.209
5.3
.252
6.4
.146
3.7
.169
4.3
.209
5.3
.252
6.4
.146
3.7
.169
4.3
.209
5.3
.252
6.4
.315
8.4
Dimension
inch
mm
W
.252
6.4
.252
6.4
.319
8.1
.374
9.5
.236
6.0
.252
6.4
.311
7.9
.366
9.3
.283
7.2
.327
8.3
.354
9.0
.354
9.0
.551
14.0
F
.256
6.5
.256
6.5
.256
6.5
.256
6.5
.256
6.5
.256
6.5
.256
6.5
.256
6.5
.295
7.5
.276
7.0
.276
7.0
.276
7.0
.413
10.5
L
.866
22.0
.866
22.0
.866
22.0
.866
22.0
.866
22.0
.866
22.0
.866
22.0
.866
22.0
.961
24.4
1.004
25.5
1.004
25.5
1.004
25.5
1.201
30.5
E
D
d1
T
.433
11.0
.177
4.5
.067
1.7
.030
0.75
• Metal Insulation Sleeve
• Molded Insulator
• Internal Barrel Serrations
• Funnel Entry
KN14-6F-M
KN14-8F-M
KN14-10F-M
KN14-14F-M
KN10-6F-D
KN10-8F-D
KN10-10F-D
KN10-14F-D
KN10-516F-D
12-10
A.W.G.
4-6
mm
2
16-14
A.W.G.
1.5-2.5
mm
2
#8
#10
1/4
#6
#8
#10
1/4
5/16
.433
11.0
.205
5.2
.091
2.3
.031
0.8
.512
13.0
.276
7.0
.134
3.4
.039
1.0
Box Quantity: (D)=500; (M)=1000
For Mylar Tape replace box quantity with (T). Example: KN18-6F-T
UL File #E9809
CSA File #LR4503
See pages in back of catalog for complete tool information.
Tool and Die Selection Chart on page M42.
Maximum Electrical Rating:
105˚C 600 Volts Max.
Terminal Material:
Copper
M
Spec-Kon
Tools used with Nylon Insulated Ring Terminals
®
ERG2500
KT-2500
