VS9MTRI-312.500EL datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> VS9MTRI-312.500EL

VS9MTRI-312.500EL: DescriptionLVPECL Output Clock Oscillator, 0.75MHz Min, 800MHz Max, 312.5MHz Nom; CategoryPassive components oscillator; File Size629KB，3 Pages; ManufacturerRaltron; Websitehttp://www.raltron.com/; Environmental Compliance

Download Datasheet Parametric View All

VS9MTRI-312.500EL Overview

LVPECL Output Clock Oscillator, 0.75MHz Min, 800MHz Max, 312.5MHz Nom

VS9MTRI-312.500EL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Raltron
package instruction	DILCC6,.2
Reach Compliance Code	compliant
Other features	TAPE AND REEL; TRI-STATE ENABLE DISABLE FUNCTION; 45/55 MINIMUM SYMMETRY AVAILABLE
Maximum control voltage	3.3 V
Minimum control voltage
maximum descent time	1 ns
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	25 ppm
frequency stability	50%
JESD-609 code	e4
linearity	10%
Manufacturer's serial number	VS9M
Installation features	SURFACE MOUNT
Number of terminals	6
Maximum operating frequency	800 MHz
Minimum operating frequency	0.75 MHz
Nominal operating frequency	312.5 MHz
Maximum operating temperature	50 °C
Minimum operating temperature
Oscillator type	LVPECL
Output load	50 OHM
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	DILCC6,.2
physical size	7mm x 5mm x 2mm
power supply	3.3 V
Certification status	Not Qualified
longest rise time	1 ns
Maximum slew rate	100 mA
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)

Preview

Download Datasheet

View All

VCXO

Page 1 of 3

VS9M: ANALOG MULTIPLIED LVPECL SERIES: ULTRA HF VCXO, LVPECL, +3.3 VDC

DESCRIPTION: A crystal controlled, high frequency, highly stable oscillator, adhering to Low Voltage Differential Signaling

(LVPECL) Standards. The output can be Tri-stated to facilitate testing or combined multiple clocks. The device is contained in

a sub-miniature, very low profile, leadless ceramic SMD package with 6 gold contact pads. This miniature oscillator is ideal for

today's automated assembly environments.

APPLICATIONS AND FEATURES:

Infiniband; Fiber Channel; SATA; 10GbE; Network Processors; SOHO Routing; Switches;

Common Frequencies: 150 MHz; 156.25 MHz; 155.52 MHz; 161.1328 MHz; 212.5MHz; 312.5MHz, 622.080 MHz

+3.3 VDC LVPECL

Frequency Range from 750KHz to 800MHz

Low Phase Noise Analog Multiplication

Miniature Ceramic SMD Package Available on Tape and Reel

Lead Free and ROHS Compliant

SYMBOL

T(stg)

Vcc

SYMB

Vcc

VALUE

-40…+85

-55…+90

+4.6

Vss-0.5…Vcc+0.5

TEST CONDITIONS

UNIT

°C

VDC

ABSOLUTE MAXIMUM RATINGS:

PARAMETER

Operating temperature range

Storage temperature range

Supply voltage

Maximum Input Voltage

Maximum Output Voltage

ELECTRICAL PARAMETERS:

PARAMETER

VALUE

0.75 to 800

+3.3

±5%

100.0 MAX

LVPECL

Vcc-1.025

Vcc-1.620

40/60 to 60/40 or 45/55 to 55/45

0.7 TYP 1.0 MAX

±50

*(note 7)

0.3 TYP**

6 TYP **

18 TYP **

2.5 TYP **

2.5 TYP**

30 TYP**

43 TYP**

-65

-95

-125

-140

-145

-148

-50

-35

0 to +3.3

+1.65

0.25

10 MIN

0.7•Vcc MIN

0.3•Vcc MAX

0.7•Vcc MIN

0.3•Vcc MAX

UNIT

MHz

VDC

Ω

VDC

ppm

dBc/Hz

dBc

VDC

ppm

KΩ

KHz

VDC

Nominal Frequency

Supply Voltage

Supply Current

Output Logic Type

Load

Output Voltage Levels

Duty Cycle

Rise / Fall Time

Frequency Stability

Voh

Vol

tr / tf

Connected between each output and Vcc – 2.0 VDC

min

max

Measured at 50% of output voltage swing

Measured at 20/80% and 80/20% output voltage swing

Overall conditions

Integrated Phase tji RMS, Fj = 12 kHz…20 MHz

Deterministic period Jitter Dj using

wavecrest analyzer

Random period Jitter Rj using

wavecrest analyzer

Acumm. Peak to Peak Jitter Tp-p using

wavecrest analyzer

Fo<320MHz.

Fo>320MHz.

Fo<320MHz.

Fo>320MHz.

Fo<320MHz.

Fo>320MHz.

∆f=10

∆f=100

∆f=1

KHz

∆f=10

KHz

∆f=100

KHz

∆f>1M

Fo<320MHz.

Fo>320MHz.

Integrated Phase RMS ti offset frequency 50KHz to 80MHz

0.5 TYP**

Jitter

Phase Noise,TYP

£(∆f)

typ. @212.5MHz

Sub Harmonics, TYP

Control Voltage Range

Settability

Absolute Pull Range

Input Impedance

Modulation Bandwidth

Enable High Option;

Pin 2

Output Enabled

Output Disabled

Enable Low Option;

Pin 2

Output Disabled

Output Enabled

f_sub Load, nom, Supply nom

Vfo

APR

Zin

Dis

Positive slope; 10% linearity MAX

Minimum guaranteed freq. pull over

∆f/fc,

over all conditions See Part Numbering

-3 dB

High Voltage or No Connect

Ground

High Voltage

Ground or No Connect

RALTRON ELECTRONICS CORP.

10651 N.W . 19

Miami, Florida 33172

U.S.A.

phone: (305) 593-6033

fax: (305) 594-3973

e-mail: sales@raltron.com

WEB: http://www.raltron.com
