• All inputs except data & DM are sampled at the positive going edge of the
system clock (CK).
• Data I/O transactions on both edges of data strobe, DM for masking.
• Edge aligned data output, center aligned data input.
• No DLL; CK to DQS is not synchronized.
• DM for write masking only.
• Auto refresh duty cycle.
- 7.8us
• Clock stop capability
• 2/CS, 2CKE
Operating Frequency
DDR400
Speed @CL3
1)
NOTE :
1) CAS Latency
200MHz
Address configuration
Organization
64Mx32
64Mx32
/CS
CS0
CS1
CKE
CKE0
CKE1
Bank
BA0,BA1
BA0,BA1
Row
A0 - A13
A0 - A13
Column
A0 - A9
A0 - A9
- DM is internally loaded to match DQ and DQS identically.
-3-
KBY00U00VA-B450
datasheet
Rev. 1.0
MCP Memory
2. GENERAL DESCRIPTION
The KBY00U00VA is a Multi Chip Package Memory which combines 8Gbit DDP Nand Flash Memory(organized with two pieces of 4Gbit Nand Flash
Memory) and 4Gbit DDR synchronous high data rate Dynamic RAM(organized with two pieces of 2Gbit Mobile DDR SDRAM).
NAND cell provides the most cost-effective solution for the solid state application market. A program operation can be performed in typical 420μs(TBD) on
the (2K+64)Word page and an erase operation can be performed in typical 3ms(TBD) on a (128K+4K)Word block. Data in the data register can be read
out at 42ns cycle time per Word. The I/O pins serve as the ports for address and data input/output as well as command input. The on-chip write controller
automates all program and erase functions including pulse repetition, where required, and internal verification and margining of data. Even the write-
intensive systems can take advantage of the device′s extended reliability of TBD program/erase cycles by providing ECC(Error Correcting Code) with real
time mapping-out algorithm. The device is an optimum solution for large nonvolatile storage applications such as solid state file storage and other portable
applications requiring non-volatility.
In 4G bit DDP Mobile DDR, Synchronous design make a device controlled precisely with the use of system clock. Range of operating frequencies, pro-
grammable burst length and programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory sys-
tem applications.
The KBY00U00VA is suitable for use in data memory of mobile communication system to reduce not only mount area but also power consumption. This
