RoHS
AS30
Axial Shielded Inductors
Allied
Part
Number
AS30-R10K-RC
AS30-R12K-RC
AS30-R15K-RC
AS30-R18K-RC
AS30-R22K-RC
AS30-R27K-RC
AS30-R33K-RC
AS30-R39K-RC
AS30-R47K-RC
AS30-R56K-RC
AS30-R68K-RC
AS30-R82K-RC
AS30-1R0K-RC
AS30-1R2K-RC
AS30-1R5K-RC
AS30-1R8K-RC
AS30-2R2K-RC
AS30-2R7K-RC
AS30-3R3K-RC
AS30-3R9K-RC
AS30-4R7K-RC
AS30-5R6K-RC
AS30-6R8K-RC
AS30-8R2K-RC
AS30-100K-RC
AS30-120K-RC
AS30-150K-RC
AS30-180K-RC
AS30-220K-RC
AS30-270K-RC
AS30-330K-RC
AS30-390K-RC
AS30-470K-RC
AS30-560K-RC
AS30-680K-RC
AS30-820K-RC
AS30-101K-RC
AS30-121K-RC
AS30-151K-RC
AS30-181K-RC
AS30-221K-RC
AS30-271K-RC
AS30-331K-RC
AS30-391K-RC
AS30-471K-RC
AS30-561K-RC
AS30-681K-RC
AS30-821K-RC
AS30-102K-RC
AS30-122K-RC
AS30-152K-RC
AS30-182K-RC
AS30-222K-RC
AS30-272K-RC
AS30-332K-RC
AS30-392K-RC
AS30-472K-RC
AS30-562K-RC
AS30-682K-RC
AS30-822K-RC
AS30-103K-RC
Inductance Tolerance
(µh)
(%)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
Min.
42
42
42
42
42
42
42
42
41
39
36
35
42
38
38
38
38
38
38
40
42
42
45
47
51
51
45
43
42
37
46
38
42
41
46
46
43
50
49
56
53
57
57
57
50
50
56
49
49
50
50
50
55
55
55
50
50
45
45
45
45
Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.25
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
.250
.250
.250
.250
.250
.250
.250
.250
.250
.250
.250
.250
SRF
Min.
(MHz)
500
500
500
336
331
298
288
271
247
236
216
200
136
120
111
103
94.0
84.8
78.4
72.8
66.4
61.6
54.6
49.6
44.0
39.2
44.0
40.0
36.0
32.8
29.6
26.4
23.2
21.6
18.4
16.8
15.2
14.4
12.0
11.2
9.60
9.20
8.40
8.00
6.80
6.00
5.60
5.20
4.80
3.25
2.91
2.63
2.58
2.40
2.07
2.00
1.83
1.79
1.60
1.56
1.50
DCR
Max.
(Ω)
.112
.126
.136
.165
.198
.220
.258
.292
.360
.397
.472
.638
.208
.225
.265
.285
.330
.381
.432
.576
.787
1.04
1.40
1.68
2.58
3.65
.862
1.02
1.12
1.28
1.70
1.99
2.41
2.85
3.21
3.57
4.10
5.97
7.05
8.42
14.8
16.8
18.6
21.1
32.2
36.4
41.1
45.0
52.0
22.4
29.4
33.0
38.0
42.0
58.5
77.0
86.2
111
128
145
168
Rated
Current
(mA)
1720
1630
1550
1420
1330
1230
1140
1060
960
915
840
720
1260
1210
1120
1080
1000
935
875
755
650
565
485
440
355
300
620
570
545
510
440
405
370
340
320
305
280
235
215
200
150
140
130
120
100
95
90
85
80
100
90
84
79
75
63.5
55.5
52.5
46.0
42.6
40.5
31.6
24AWG
1.15
(29)
NOMINAL
0.335
(8.51)
MAX.
1.15
(29)
NOMINAL
Dimensions:
0.14±0.02
(3.56±0.51)
Inches
(mm)
Electrical
Rated Current:
Inductance Drop <10%
at rated current.
Tolerance:
±10%
over the entire
inductance range. Tighter tolerances
available.
Shielding:
< 5% coupling, with 2 units
side by side at 1 KHz.
Test Procedures:
L & Q Measured with
HP4342A Q-Meter at specified Frequency.
DCR Measured on CH-301 SRF
Measured on HP-4191A, HP4291B.
Operating Temp.:
-55°C to + 125°C.
Design:
To meet MIL-C-15305, Grade 1,
Class B.
Physical
Marking (On Part):
5 Band Color Code
per MIL-C-15305.
Marking (On Reel):
Manufactures Name,
Part Number, Customers Part Number,
Invoice Number, Lot or Data Code.
Packaging (bulk):
1000 pieces per bag.
Packaging (tape & reel):
5000 pieces per
reel.
For Tape and Reel packaging please
add ”-TR” to the part number.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 10/01/10
www.alliedcomponents.com
