RoHS
Power Chip Inductors
Dimensions:
Inches
(mm)
PC1307
Allied
Part
Number
PC1307-1R5M-RC
PC1307-2R2M-RC
PC1307-2R7M-RC
PC1307-3R3M-RC
PC1307-4R7M-RC
PC1307-5R6M-RC
PC1307-6R8M-RC
PC1307-8R2M-RC
PC1307-100M-RC
PC1307-120M-RC
PC1307-150M-RC
PC1307-180M-RC
PC1307-220M-RC
PC1307-270M-RC
PC1307-330M-RC
PC1307-390M-RC
PC1307-470M-RC
PC1307-560M-RC
PC1307-680M-RC
PC1307-820M-RC
PC1307-101M-RC
PC1307-121M-RC
PC1307-151M-RC
PC1307-181M-RC
PC1307-221M-RC
PC1307-271M-RC
PC1307-331M-RC
PC1307-391M-RC
PC1307-471M-RC
PC1307-561M-RC
PC1307-681M-RC
PC1307-821M-RC
PC1307-102M-RC
Q
Inductance Tolerance Q Test
(uh)
(%)
Freq. Ref
(MHz)
MHz 0.1V
1.5
2.2
2.7
3.3
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
271
330
391
470
560
680
820
1000
20
20
20
20
20
20
20
20
20
20
20
20
20
20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
10,20
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
20
22
24
26
25
24
24
24
22
25
28
28
40
35
35
28
24
22
24
18
25
20
20
18
15
15
15
12
12
10
10
10
10
SRF
(MHz)
Typ
65
50
40
38
36
28
26
24
22
20
17
16
15
11
10
9.0
7.5
7.2
7.0
6.0
5.8
5.5
4.5
4.0
3.8
3.5
3.2
2.5
2.2
2.0
1.6
1.5
1.4
RDC
(mΩ)
Typ
5.0
6.0
8.0
8.7
10
15
17
19
21
30
34
36
47
60
65
75
82
95
120
140
180
210
250
280
360
410
520
600
720
880
1000
1300
1600
Isat
(A)
Typ
20
18
16
15
13
11
10.5
9.8
9.2
8.0
7.5
7.0
6.5
5.5
5.0
4.6
4.2
3.8
3.5
3.2
3.0
2.8
2.6
2.3
2.1
1.8
1.6
1.5
1.4
1.3
1.2
1.1
1.0
Irms
(A)
Max.
9.5
9.0
8.2
7.5
7.0
6.5
6.0
5.8
5.6
4.8
4.5
4.2
3.6
3.3
3.1
2.9
2.7
2.5
2.3
2.1
1.9
1.8
1.6
1.5
1.3
1.2
1.2
1.0
0.9
.85
.80
.75
.65
Features
• Unshielded SMD Power Inductor
• High Saturation Current
• Suitable for large currents
• Ideal for DC-DC converter applications
Electrical
Inductance Range:
1.5µh to 1000µh
Tolerance:
20% over entire range
Also available in tighter tolerances
Test Frequency:
As noted
Operating Temp:
-40ºC ~ +125ºC
IDC:
Current at which Inductance drops 10%
of original value with a
∆
T= 40½C whichever
is lower.
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 Min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC for 10 sec ± 1 sec.
Test Equipment
(L):
HP4192A LF Impedence Analyzer
(RDC):
Chen Hwa 502BC
(IDC):
HP4284A with HP42841A or
Chen Hwa 1061 + 301A
(SRF):
HP4286A
Physical
Packaging:
300 pieces per 7 inch reel.
Marking:
EIA Inductance Code.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 11/1/10
www.alliedcomponents.com
