UNISONIC TECHNOLOGIES CO., LTD
10N50
Preliminary
Power MOSFET
10 Amps, 500 Volts
N-CHANNEL POWER MOSFET
1
DESCRIPTION
The UTC
10N50
is an N-channel mode power MOSFET using
UTC’s advanced technology to provide customers with planar stripe
and DMOS technology. This technology allows a minimum on-state
resistance and superior switching performance. It also can withstand
high energy pulse in the avalanche and commutation mode.
The UTC
10N50
is generally applied in high efficiency switch
mode power supplies, active power factor correction and electronic
lamp ballasts based on half bridge topology.
TO-220
1
TO-220F1
FEATURES
* 10A, 500V, R
DS(ON)
=0.61Ω @ V
GS
=10V
* High Switching Speed
* 100% Avalanche Tested
SYMBOL
2.Drain
1.Gate
3.Source
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
10N50L-TA3-T
10N50G-TA3-T
10N50L-TF1-T
10N50G-TF1-T
Note: Pin Assignment: G: Gate D: Drain
S: Source
Package
TO-220
TO-220F1
Pin Assignment
1
2
3
G
D
S
G
D
S
Packing
Tube
Tube
www.unisonic.com.tw
Copyright © 2011 Unisonic Technologies Co., Ltd
1 of 6
QW-R502-531.a
10N50
PARAMETER
Drain-Source Voltage
Gate-Source Voltage
Preliminary
SYMBOL
V
DSS
V
GSS
I
D
I
DM
I
AR
E
AS
E
AR
dv/dt
Power MOSFET
RATINGS
500
±30
10 (Note2)
40 (Note
2)
UNIT
V
V
A
A
A
mJ
mJ
V/ns
ABSOLUTE MAXIMUM RATINGS
(T
C
=25°C, unless otherwise specified)
Continuous (T
C
=25°C)
Pulsed (Note
3)
Avalanche Current (Note
3)
Single Pulsed (Note
4)
Avalanche Energy
Repetitive (Note
5)
Peak Diode Recovery dv/dt (Note
5)
Drain Current
10
388
14.3
4.5
TO-220
143
T
C
=25°C
W
TO-220F1
48
P
D
Power Dissipation
TO-220
1.14
Derate above 25°C
W/°C
TO-220F1
0.38
Junction Temperature
T
J
+150
°C
Storage Temperature
T
STG
-55~+150
°C
Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. Drain current limited by maximum junction temperature
3. Repetitive Rating: Pulse width limited by maximum junction temperature
4. L = 7mH, I
AS
= 10A, V
DD
= 50V, R
G
= 25Ω, Starting T
J
= 25°C
5. I
SD
≤
10A, di/dt
≤
200A/µs, V
DD
≤
BV
DSS
, Starting T
J
= 25°C
THERMAL DATA
PARAMETER
Junction to Ambient
Junction to Case
TO-220
TO-220F1
TO-220
TO-220F1
SYMBOL
θ
JA
θ
JC
RATINGS
62.5
62.5
0.87
2.58
UNIT
°C/W
°C/W
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 6
QW-R502-531.a
10N50
Preliminary
Power MOSFET
ELECTRICAL CHARACTERISTICS
(T
C
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
BV
DSS
I
D
=250µA, V
GS
=0V
Drain-Source Leakage Current
I
DSS
V
DS
=500V, V
GS
=0V
Forward
V
GS
=+30V, V
DS
=0V
Gate- Source Leakage Current
I
GSS
Reverse
V
GS
=-30V, V
DS
=0V
ON CHARACTERISTICS
Gate Threshold Voltage
V
GS(TH)
V
DS
=V
GS
, I
D
=250µA
Static Drain-Source On-State Resistance
R
DS(ON)
V
GS
=10V, I
D
=5A
DYNAMIC PARAMETERS
Input Capacitance
C
ISS
V
GS
=0V, V
DS
=25V, f=1.0MHz
Output Capacitance
C
OSS
Reverse Transfer Capacitance
C
RSS
SWITCHING PARAMETERS
Total Gate Charge
Q
G
V
GS
=10V, V
DS
=400V, I
D
=10A
Gate to Source Charge
Q
GS
(Note 6, 7)
Gate to Drain Charge
Q
GD
Turn-ON Delay Time
t
D(ON)
Rise Time
t
R
V
DD
=250V, I
D
=10A, R
G
=25Ω
(Note 6, 7)
Turn-OFF Delay Time
t
D(OFF)
Fall-Time
t
F
SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS
Maximum Body-Diode Continuous Current
I
S
Maximum Body-Diode Pulsed Current
I
SM
Drain-Source Diode Forward Voltage
V
SD
I
S
=10A, V
GS
=0V
Body Diode Reverse Recovery Time
t
RR
I
S
=10A, V
GS
=0V, dI
F
/dt=100A/µs
(Note 6)
Body Diode Reverse Recovery Charge
Q
RR
Notes: 6. Pulse Test: Pulse width
≤
300µs, Duty cycle
≤
2%
7. Essentially independent of operating temperature
MIN TYP MAX UNIT
500
V
1
µA
+100 nA
-100 nA
4.0
0.61
V
Ω
pF
pF
pF
nC
nC
nC
ns
ns
ns
ns
A
A
V
ns
µC
2.0
0.5
1610 2096
177 230
16
24
43
56
7.5
18.5
29
67
80 170
141 290
80 165
10
40
1.4
50
0.1
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 6
QW-R502-531.a
10N50
Gate Charge Test Circuit
