UNISONIC TECHNOLOGIES CO., LTD
82XX
Preliminary
LINEAR INTEGRATED CIRCUIT
MONOLITHIC IC 82XX SERIES
DESCRIPTION
The normal operation of the UTC
82XX
is that while the power
is turned on or interrupted, detect power supply voltage and then
reset the system accurately.
The internal circuits of the UTC
82XX
include a built-in fixed
delay time generating circuit. With a counter timer using an
analog/digital hybrid circuit, the UTC
82XX
as new low reset type
system reset ICs expands the delay time series.
These ICs can be used in a variety of CPU systems and other
logic systems.
FEATURES
* Internal Fixed Delay Time Setting by Counter Timer
* Grate Delay Time Temperature Characteristics:±800ppm/°C
* Operating Limit Voltage as 0.65V(Typ.)
* Hysteresis Voltage Provided: 50mV(Typ.)
*
Circuit Current While On
I
CCL
=300µA(Typ.)
*
Circuit Current While Off
I
CCH
=200µA(Typ.)
* Halogen Free
ORDERING INFORMATION
Ordering Number
Package
82XXG-x-AF5-R
SOT-25
Notes: xx: Output Voltage, refer to Marking Information.
x : Delay Time, refer to Electrical Characteristics of
"H" Transport Delay Time
Packing
Tape Reel
www.unisonic.com.tw
Copyright © 2010 Unisonic Technologies Co., Ltd
1 of 8
QW-R502-326.c
82XX
PACKAGE
Preliminary
LINEAR INTEGRATED CIRCUIT
MARKING INFORMATION
VOLTAGE CODE
25:2.5V
SOT-25
27:2.7V
2K:2.93V
Month
MARKING
3
2
XXXX
4
5
X
1
Voltage
Code
L: Lead Free
G: Halogen Free
PIN CONFIGURATION
RESET NC
3
2
V
OUT
1
4
V
CC
5
GND
PIN DESCRIPTION
PIN NO.
1
2
3
4
5
PIN NAME
V
OUT
NC
RESET
V
CC
GND
DESCRIPTION
Output pin
Connected nothing
Reset control pin
Supply voltage
Ground
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 8
QW-R502-326.c
82XX
BLOCK DIAGRAM
Preliminary
LINEAR INTEGRATED CIRCUIT
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
47K
47K
3 of 8
QW-R502-326.c
82XX
Preliminary
LINEAR INTEGRATED CIRCUIT
ABSOLUTE MAXIMUM RATING
(Ta=25°C)
PARAMETER
SYMBOL
RATINGS
UNIT
Power Supply Voltage
V
CC
-0.3~+10
V
Manual Reset Input Voltage
V
RESET
-0.3~+10
V
Power Dissipation
P
D
400
mW
Operating Temperature
T
OPR
-20~+75
°C
Storage Temperature
T
STG
-40~+125
°C
Note:
Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS
(Ta=25°C, Unless otherwise specified)
V
S
=2.5V~2.93V
PARAMETER
Detection Voltage
Low-Level Output Voltage
Operating Power Supply Voltage
Hysteresis Voltage
Detection Voltage Temperature
Coefficient
Output Leakage Current
On
Circuit Current
Off
I
CCH
SYMBOL
V
S
V
OL
V
OPL
ΔV
S
VS
Δ
T
I
OH
I
CCL
TEST CONDITIONS
V
OL
≤0.4V,
V
CC
=H→L, R
L
=470Ω
(See Test Circuit 1)
V
CC
=V
S(min)
-0.05V, R
L
=470Ω
(See Test Circuit 1)
R
L
=4.7kΩ, V
OL
≤0.4V
V
CC
=L→H→L , R
L
=470Ω
(See Test Circuit 1)
R
L
=470Ω, Ta=-20°C~+75°C
(See Test Circuit 1)
V
CC
=10V (See Test Circuit 1)
V
CC
= V
S(min)
-0.05V, R
L
=∞
(See Test Circuit 1)
V
CC
=V
S(Typ)
/0.85V, R
L
=∞
(See Test Circuit 1)
P
Q
R
L
=4.7KΩ, C
L
=100PF (Note 1)
R
(See Test Circuit 2)
S
T
R
L
=4.7kΩ, C
L
=100PF (Note 1)
(See Test Circuit 2)
V
CC
=VS min.-0.05V, R
L
=0Ω
(See Test Circuit 1)
Ta=-20°C ~+75°C, R
L
=0Ω(Note 2)
(See Test Circuit 1)
MIN
V
S
-0.15V
TYP
V
S
0.1
0.65
MAX UNIT
V
S
V
+0.15V
0.4
0.85
100
V
V
mV
%/°C
±0.1
µA
µA
µA
mS
mS
mS
mS
mS
µS
mA
mA
80
0.8
V
µA
V
30
50
±0.01
300
200
30
60
120
240
480
50
100
200
400
800
10
8
6
2.0
600
350
75
150
300
600
1200
"H" Transport Delay Time
t
PLH
"L" Transport Delay Time
Output Current While on 1
Output Current While on 2
t
PHL
I
OL1
I
OL2
Input High Voltage
V
RESH
Manual Reset
Input High Current
I
RESH
V
RESET
=2V
Pin
Input Low Voltage
V
RESL
Notes: 1. t
PLH
: V
CC
= (V
S(TYP)
-0.4V) (V
S(TYP)
+0.4V)
t
PHL
: V
CC
= (V
S(TYP)
+0.4V) (V
S(TYP)
-0.4V)
2. V
CC
=V
S(MIN)
-0.15V
3. V
OUT
pin is low when manual reset pin is high.
V
OUT
pin is high when manual reset pin is low.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 8
QW-R502-326.c
82XX
TEST CIRCUITS
Preliminary
LINEAR INTEGRATED CIRCUIT
A1
A2
V
CC
10µF/10V
R
L
V
CC
V1
MANUAL
RESET
GND
V
OUT
V2
Test Circuit 1
A: DC ammeter
V: DC voltmeter
CRT: Oscilloscope
V
CC
0.2µF/10V
INPUT
PULSE
R
L
=4.7K
V
OUT
10µF/10V
GND
C
L=
100pF
CRT
MANUAL
RESET
5.0V
(2)INPUT PULSE
0.8V
V
S
0V
4.9
4.1
Note Input model is an example for 82XX
Test Circuit 2
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 8
QW-R502-326.c
