F-210 SUPPLEMENT
MODM–D–02–8P8C–U–S4–Y–G
MODM-D, MODM-E SERIES
MODM–E–04–8P8C–L–S4–Y–G
GANGED MODULAR JACKS WITH LEDS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?MODM-D
or www.samtec.com?MODM-E
Insulator Material:
MODM-D: PBT
Glass Filled
FILE NO. E225096
MODM-E: Nylon 46
FILE(MODM-D)
NO. E244987
Contact Material:
(MODM-E)
Phosphor Bronze
Shield Material:
Copper Alloy
Plating:
Gold on Contacts,
Nickel on Shield, Gold on Tails
Operating Temp Range:
-25°C to +90°C
Current Rating:
1.5 A per contact
Voltage Rating:
120 VAC max
Contact Resistance:
20 mΩ max
Minimum Cycles:
500
System Applications:
CAT3
Packaging:
Packaged and shipped in
Bulk Packaging Trays; Trays
suitable for automation are
available upon request.
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes (Wave Solder only)
MODS-D & -E FEATURES
Category
Orientation
Shielding
Termination
Tab Orientation
Tab Orientation
Profile (-D)
Profile (-E)
LEDs
RJ45 Stacked
RJ45 In-line
CAT3
Side Entry, Ganged
Shielded, with or without
Panel Grounds
Through-Hole
Top Up, Bottom Down (-D)
Tab Up (-E)
(25,40mm) 1.000" +pnl gnds
(13,70mm) .545" +pnl gnds
Standard
MODM-D-XX-8P8C-X-XX-X-X
MODM-E-XX-8P8C-X-XX-X-X
8 Positions,
8 Contacts
Choice of
LED Color
Shielded
Selectively
Plated
Contacts
APPLICATION
SPECIFIC OPTION
Other plating options available.
Call Samtec.
Stacked or
In-line
2, 4 or 8 Ports
MODM
TYPE
NO. OF
PORTS
8P8C
–8P8C
= 8 Positions
8 Contacts
PLATING
SHIELD
OPTION
LED
1
LED
2
–D
= Stacked
–E
= In-line
–02,
–04,
–08
–L
= 15µ" (0,38 µm)
Gold on Mating Area,
Gold Flash on Tails
–S
= Shielded
(No Panel
Grounds)
–G
= Green
–Y
= Yellow
–U
Top
LED1
–S4
= Shielded
with Top,
Bottom and
Side Panel
Grounds
–1*
= Green/Orange
A
Top
LED2
(28,15) 1.108
= 50µ" (1,27µm)
Gold on Mating Area,
Gold Flash on Tails
–3*
= Green/Red
(25,40)
1.000
–4*
= Yellow/Red
NO. OF
PORTS
–02
–04
(5,46)
.215
(1,30) .051
–D
A
(16,51)
.650
(32,26)
1.270
(63,65)
2.506
–E
B
A
B
(32,26) (28,45)
1.270 1.120
(63,80) (59,94)
2.512 2.359
(126,75) (122,94)
4.990 4.840
Bottom
LED1
Bottom
LED2
(2,74)
.108
–6*
= Yellow/Green
(3,10)
.122
(2,54)
.100
(3,50)
.138
B
MODM-D
Top LED2
–08
(12,70)
.500
(28,45)
1.120
(59,95)
2.360
–N
= No LED
(–E only)
(LED1 –N
requires
LED2 –N)
Top LED1
A
(0,35)
.014
(15,75)
.620
*
Voltage
Forward/Reverse
(13,60)
.535
(0,25)
.010
(2,54)
.100
(8,83) .348
(2,54)
.100
(2,74) .108
B
(5,40)
.213
MODM-E
WWW.SAMTEC.COM
