BTRS-9780-1510-SPG

Description
1510 nm TX / 1590 nm RX , 3.3V / 2.5 Gbps RoHS Compliant Single-FiberWDM Transceiver
File Size124KB,6 Pages
ManufacturerOptoway
Websitehttp://www.optoway.com
Download Datasheet Compare View All

BTRS-9780-1510-SPG Overview

1510 nm TX / 1590 nm RX , 3.3V / 2.5 Gbps RoHS Compliant Single-FiberWDM Transceiver

Optoway
FEATURES
l
l
l
l
l
l
l
l
l
l
l
l
l
BTRS-9780-1510G
1
**********************************************************************************************************************************************************************
BTRS-9780-1510G / BTRS-9780-1510-SPG / BTRS-9780A-1510G / BTRS-9780A-1510-SPG
1510 nm TX / 1590 nm RX , 3.3V / 2.5 Gbps
RoHS Compliant
Single-Fiber WDM Transceiver
*********************************************************************************************************************************************************************
DESCRIPTION
Single Fiber WDM Transceiver
Speed up to 2.67 Gbps
1510 nm DFB LD Transmitter
High Sensitivity 1590 nm APD Receiver
Distance Up to 80 km
Single +3.3 V Power Supply
RoHS Compliant
PECL Differential Inputs and Outputs
LVTTL Signal Detect Output
0 to 70
o
C Operating: BTRS-9780-1510G
-20 to 85
o
C Operating: BTRS-9780A-1510G
Wave Solderable and Aqueous Washable
Class 1 Laser International Safety Standard IEC 60825
Compliant
The BTRS-9780-1510G series is high performance module
for single fiber communications by using 1510 nm
transmitter and 1590 nm receiver. The transmitter section
uses a multiple quantum well 1510 nm DFB laser and is a
class 1 laser compliant according to International Safety
Standard IEC 60825. The receiver section uses an integrated
1590 nm detector preamplifier (IDP) mounted in an optical
header and a limiting post-amplifier IC. A PECL logic
interface simplifies interface to external circuitry. LV-TTL
Signal Detect is used.
LASER SAFETY
This single mode transceiver is a Class 1 laser product. It
complies with IEC 60825 and FDA 21 CFR 1040.10 and
1040.11. The transceiver must be operated within the
specified temperature and voltage limits. The optical ports
of the module shall be terminated with an optical connector
or with a dust plug.
APPLICATIONS
l
WDM OC-48 / STM-16 Links
l
SONET/SDH Equipment Interconnect
l
Fiber Channel Links
ORDER INFORMATION
P/No.
Speed
(Gb/s)
Distance
(km)
80
80
TX
(nm)
1510 DFB
1510 DFB
RX
(nm)
1590
1590
Voltage
(V)
3.3
3.3
Package
Temp
(
o
C)
0 to 70
-20 to 85
TX
Power
(dBm)
3 to -2
3 to -2
RX Sens.
(dBm)
-28
-28
BTRS-9780-1510G 2.5 / 1.25
BTRS-9780A-1510G
2.5 / 1.25
2X5 SC
2X5 SC
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Temperature
Symbol
Tstg
Topr
Min
-40
0
-20
Max
85
70
85
260
3.6
Vcc
30
Units
o
C
o
C
Notes
BTRS-9780-1510G
BTRS-9780A-1510G
Air flow 1m/sec
10 seconds on leads only
Soldering Temperature
Power Supply Voltage
Input Voltage
Output Current
---
Vcc
---
Iout
o
0
GND
0
C
V
V
mA
Recommended Operating Conditions
Parameter
Power Supply Voltage
Power supply Current
Operating Temperature
Symbol
Vcc
Icc,
TX
+Icc,
RX
Topr
Min
3.13
0
-20
0.622
2.488
Typ
3.3
220
Max
3.47
280
70
85
2.67
Units / Notes
V
mA
o
C / BTRS-9780-1510G
o
C / BTRS-9780A-1510G
air flow 1m/sec
Gb/s
Data Rate
**********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
10/1/2009 V2.0
