Designing and manufacturing innovative frequency control devices since 1927
Miniature, Ceramic, Surface Mount Crystal
SM60
Monitor’s SM60 provides a miniature crystal in a highly reliable package
that is specifically designed for surface mount applications.
Hermetically-sealed construction ensures long term stability and
exceptional aging characteristics.
APPLICATIONS
M
M
M
M
M
Wireless RF
PCMCIA
Cameras
Disk Drives
PDAs
FEATURES
M
M
M
M
Ultra-slim 1.0mm profile
Surface Mount
Reflow solderable at 2601C for 10 secs max
Tape & Reel (1000pcs/reel)
SPECIFICATIONS
Frequency Range
Operating Temp Range
Storage Temp Range
Shunt Capacitance
Calibration Tolerance
@ 251C
Frequency Tolerance
vs Temp Range
Equivalent Series
Resistance
(MHz =
✡
max)
Fundamental unless otherwise
otherwise indicated
9.8304 MHz ~ 100.0 MHz*
-101C ~ 601C
-401C ~ 851C
7.0 pF max
!
10ppm,
!
25ppm &
!
50ppm options available
!
50ppm from -101C ~ 601C standard
(call for other options)
9.8304
10.0000
16.0000
28.0000
84.0000
~
~
~
~
~
9.9999
15.9999
32.0000
83.9999
100.0000
=
=
=
=
=
80
60
40
60 (3rd Overtone)
80 (5th Overtone)
Units = mm
Drive Level
Humidity
Hermetic Seal
Solderability
Vibration
Shock
Packaging
0.1 mW max
85% RH, 851C, 48 Hours
Leak Rate 2 x 10
-8
ATM-cm
3
/sec max
MIL-STD-202F Method 208E
MIL-STD-202F Method 204 / 35G, 50~2000 Hz
(<25.0 MHz) / 20G, 50~2000 Hz (25.0 MHz)
MIL-STD-202F Method 213B Test Cond E,
1000G, 1/2 Sine Wave
16mm Tape & Reel (1000pcs/reel std, or Bulk <1000pcs)
* Call for your specific frequency requirement
SM60
Monitor Products Company Inc reserves the right to make changes to its products and product specifications without notice. No liability is assumed as a result of their use or application.
07-02-01
502 VIA DEL MONTE, OCEANSIDE, CA 92054
TEL:
760.433.4510
FAX:
760.434.0255
SM60
Units = mm
TAPE DIMENSIONS (1000 pcs/reel)
REEL DIMENSIONS
CRYSTAL CORRELATION THEORY
Series Resonance:
At series resonance, the crystal looks
resistive in the circuit, and correlation of
frequency is not a problem. It must be
specified if unit is to be manufactured at
series or at a particular load capacitance.
Anti-Resonance Parallel:
Crystals operating at anti-resonance will look inductive
in the circuit. Changes of reactive values in the circuit
will change the crystal frequency. If the crystal is to be
used at anti-resonance, the load capacitance should
always be specified. The load capacitance CL is the
dynamic capacitance of the total circuit as measured across the crystal terminals.
PART
NUMBERING
KEY
SERIES
SM60
CORRELATION
L
M
N
O
Q
R
S
12 pF
15 pF
20 pF
32 pF
24 pF
18 pF
Series
Resonant
X = Cust spec
=
=
=
=
=
=
=
MODE
1 = Fundamental*
3 = 3rd Overtone
5 = 5th Overtone
FREQUENCY
STABILITY
F=
E=
C=
X=
!
10 ppm
!
25 ppm
!
50 ppm
Cust spec
TEMP RANGE
1=
3=
5=
9=
-101C
~ 601C*
-201C
~ 701C
-401C
~ 851C
Cust spec
PACKAGING
A = Bulk
(<1000 pcs)
E = Tape & Reel*
(1000 pcs/reel)
FREQUENCY
X = Cust spec
Sample Part Number
SM60N1C1E
@ 32.256 MHz
* Standard
=
SM80
N
1
C
1
E
32.256
Call factory for additional options. Use full descriptive part number when ordering. Parts will be marked with series and frequency only.
Monitor Products has a proven track record as a pioneer manufacturer in the frequency control market. If our extensive selection of standard and
engineered crystals and oscillators does not meet your spec, we will work with you towards a customized solution.
Monitor Products Company Inc reserves the right to make changes to its products and product specifications without notice. No liability is assumed as a result of their use or application.
07-02-01
502 VIA DEL MONTE, OCEANSIDE, CA 92054
TEL:
760.433.4510
FAX:
760.434.0255
