MAPDCT0024
2 Way 0º Power Divider
5 - 1200 MHz
Features
•
•
•
•
•
Surface Mount
2 Way
0º
RoHS* Compliant
260ºC reflow compliant
Rev. V4
Schematic with external resistor
Description
M/A-COM Technology Solutions MAPDCT0024 is a
2 Way 0
0
Power Divider in a low cost, surface mount
package. Ideally suited for high volume CATV appli-
cations. An external 160Ω Chip resistor is required
with this part.
Component Dimensions:
3.50mm
1
6
7.20mm
R3.13mm
2
3
TOP VIEW
5
4
SIDE VIEW
2.65mm
Pin Configuration
Pin No.
Function
3
6.55mm
4
2.85mm
1.04mm
Input
Ground
Not Connected
Port 1
Port 2
6
1
2, 5
4
3
2
1
BOTTOM VIEW
5
6
Recommended PCB Design
1.50mm
Dimensions in mm. Tolerance: ± 0.20, unless otherwise stated.
Drawing not to scale.
1
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.43537383
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
MAPDCT0024
2 Way 0º Power Divider
5 - 1200 MHz
Rev. V4
Electrical Specifications: T
A
= 25°C, Z
0
= 75Ω
Parameter
Test Conditions
Units
Min.
Typ.
Max.
Insertion Loss
(Ref. Level –3dB)
5 – 500MHz
500 – 870MHz
870 – 1002Mhz
1002 – 1200MHz
5 – 40MHz
40 – 400MHz
400 – 1200MHz
5 – 500MHz
500 – 1200MHz
5 – 40MHz
40 – 1002MHz
1002 – 1200MHz
5 – 40MHz
40 – 1002MHz
1002 – 1200MHz
dB
dB
dB
dB
dB
dB
dB
o
o
–
–
–
–
–
–
–
–
–
17
18
16
18
18
18
3.50
3.85
3.97
4.29
0.2
0.22
0.27
1.3
2.1
21.0
26.0
23.5
36.0
32.8
22.6
3.80
4.30
4.51
5.10
±0.6
±0.4
±0.6
±4.0
±6.0
–
–
–
–
–
–
Amplitude Unbalance
Phase Unbalance
Output Return Loss
dB
dB
dB
dB
dB
dB
Input Return Loss
Recommended Maximum Ratings
Parameter
RF Power
DC Current
Internal Load
Dissipation
Operating/Storage
Temperature
Recommended Max.
+30dBm (1W)
30 mA
0.125W
-40° C to +125° C
2
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.43537383
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
MAPDCT0024
2 Way 0º Power Divider
5 - 1200 MHz
Typical Performance Curves: T
A
= 25°C, Z
0
= 75Ω
Insertion Loss
0. 0
Rev. V4
Input Return Loss
0
-5
-1. 0
-10
-2. 0
-15
dB
dB
-3. 0
-20
-25
-4. 0
-30
-5. 0
-35
-6. 0
5
205
405
605
805
1005
-40
5
205
405
605
805
1005
F r eq uency ( M Hz )
F r eq uency ( M Hz )
Amplitude Unbalance
0. 8
Phase Unbalance
6
0. 6
4
0. 4
2
0. 2
Degrees
dB
0. 0
0
-0. 2
-2
-0. 4
-4
-0. 6
-6
-0. 8
5
205
405
605
805
1005
5
205
405
605
805
1005
F r eq uency ( M Hz )
Fr e que nc y ( M H z )
3
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
•
India
Tel: +91.80.43537383
•
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
MAPDCT0024
2 Way 0º Power Divider
5 - 1200 MHz
Tape & Reel Information
Rev. V4
DIRECTION OF FEED
Bo
W
Ko
P1
Orientation
Ao
Item
Ao
Bo
Ko
W
P1
Dimension
6.70mm +/- 0.1mm
7.50mm +/- 0.1mm
3.60mm +/- 0.1mm
16.00mm +/- 0.3mm
12.00mm +/- 0.1mm
Ordering Information
Part Number
MAPDCT0024TR
1000024116
Package
900 piece reel
Sample Test Board
4
