FAN4800CSNY: Description0.5 A POWER FACTOR CONTROLLER WITH POST REGULATOR, 268 kHz SWITCHING FREQ-MAX, DIP16; CategoryPower/power management The power supply circuit; File Size594KB，20 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

FAN4800CSNY Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FAN4800CSNY	-	-	View	Buy Now

FAN4800CSNY Overview

0.5 A POWER FACTOR CONTROLLER WITH POST REGULATOR, 268 kHz SWITCHING FREQ-MAX, DIP16

FAN4800CSNY Parametric

Parameter Name	Attribute value
Brand Name	Fairchild Semiconduc
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Fairchild
Objectid	1027646652
Parts packaging code	DIP
package instruction	DIP, DIP16,.3
Contacts	16
Manufacturer packaging code	16LD, MDIP, JEDEC MS-001, .300\" WIDE
Reach Compliance Code	compli
ECCN code	EAR99
compound_id	4117338
Other features	ALSO OPERATES IN AVERAGE CURRENT MODE
Analog Integrated Circuits - Other Types	POWER FACTOR CONTROLLER WITH POST REGULATOR
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	28 V
Minimum input voltage	9.3 V
Nominal input voltage	15 V
JESD-30 code	R-XDIP-T16
JESD-609 code	e3
length	19.17 mm
Number of functions	1
Number of terminals	16
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Maximum output current	0.5 A
Package body material	UNSPECIFIED
encapsulated code	DIP
Encapsulate equivalent code	DIP16,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	5.33 mm
surface mount	NO
Switch configuration	SINGLE
Maximum switching frequency	268 kHz
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm

Preview

Download Datasheet

View All

FAN4800AS/CS/01S/02S — PFC/PWM Controller Combination

December 2010

FAN4800AS/CS/01S/2S

PFC/PWM Controller Combination

Features

Pin-to-Pin Compatible with ML4800 and FAN4800

and CM6800 and CM6800A

PWM Configurable for Current Mode or

Feedforward Voltage-Mode Operation

Internally Synchronized Leading-Edge PFC and

Trailing-Edge PWM in One IC

Low Operating Current

Innovative Switching-Charge Multiplier Divider

Average-Current Mode for Input-Current Shaping

PFC Over-Voltage and Under-Voltage Protections

PFC Feedback Open-Loop Protection

Cycle-by-Cycle Current Limiting for PFC/PWM

Power-on Sequence Control and Soft-Start

Brownout Protection

Interleaved PFC/PWM Switching

Improved Efficiency at Light Load

RTCT

=4•f

PFC

=4•f

PWM

for FAN4800AS/01S

RTCT

=4•f

PFC

=2•f

PWM

for FAN4800CS/02S

Description

The highly integrated FAN4800AS/CS/01S/02S parts

are specially designed for power supplies that consist of

boost PFC and PWM. They require very few external

components to achieve versatile protections /

compensation. They are available in 16-pin DIP and

SOP packages.

The PWM can be used in either current or voltage

mode. In voltage mode, feed-forward from the PFC

output bus can reduce the secondary output ripple.

Compared with older productions, ML4800 and

FAN4800,

FAN4800AS/CS/01S/02S

have

lower

operation current that saves power consumption in

external devices. FAN4800AS/CS/01S/02S have

accurate 49.9% maximum duty of PWM that makes the

hold-up time longer. Brownout protection and PFC soft-

start functions available in this series are not available

in ML4800 and FAN4800.

To evaluate FAN4800AS/CS/01S/02S for replacing

existing FAN4800 and ML4800 boards, five things must

be completed before the fine-tuning procedure:

Change R

resister from the old value to a higher

resister: between 6MΩ to 8MΩ.

Change RT/CT pin from the existing values to

=6.8kΩ and C

=1000pF to have f

PFC

=64kHz and

PWM

=64kHz.

The VRMS pin needs to be 1.224V at V

=85 V

for universal input application from line input from

85V

to 270V

At full load, the average V

VEA

needs to be ~4.5V

and the ripple of V

VEA

needs to be less than

400mV.

For the Soft-Start pin, the soft-start current has

been reduced to half the FAN4800 capacitor.

Applications

Desktop PC Power Supply

Internet Server Power Supply

LCD TV, Monitor Power Supply

UPS

Battery Charger

DC Motor Power Supply

Monitor Power Supply

Telecom System Power Supply

Distributed Power

There are two differences from FAN4800A/C/01/02 to

FAN4800AS/CS/01S/02S:

Under-voltage protection

extended to one second.

debounce

time

Related Resources

AN-8027 - FAN480X PFC+PWM Combination

Controller Application

PWM gate clamp voltage is raised to 19V.

FAN4800AS/CS/01S/02S • Rev. 1.0.1

www.fairchildsemi.com
