PCB DRILLING DETAILS
TECHNICAL SPECIFICATIONS
MATERIAL
SHELL
INSULATORS
:
:
STEEL TIN/Zinc Cr 3 PLATED.
SELF EXTINGUISHING BLACK POLYESTER UL CLASS 94V0
THE HOUSING WILL WITHSTAND EXPOSURE TO 260-265°C
IF WE USE PROTECTIVE ADHESIVE (type Kapton or Teflon)
OR PROTECTIVE METALLIC DEVICE
CONTACTS
:
COPPER ALLOY
ORDERING INFORMATION
I
SERIES
NO.OF CONTACTS
09,15,25 & 37
:
:
:
GOLD OVER NICKEL
TIN LEAD OVER NICKEL
2
µ
MIN.MATTE TIN TOP OVER
1.27
µ
MIN.NICKEL UNDER PLATE(ON TERMINATION ZONE)
BRASS,TIN/Zinc Cr 3 PLATED.
BRASS,TIN PLATED.
BRASS,TIN/Zinc Cr 3 PLATED.
BRASS,TIN/Zinc Cr 3 PLATED.
BRASS,TIN/Zinc Cr 3 PLATED.
D
2
5
S
3
3
E
4
G
X
2
8
L
F
LEAD FREE
SPECIAL CODE
PLATING
ACTIVE ZONE
TERMINATION ZONE
FOR LEAD FREE PLATING
28->SC.FOR FEM.SCREW LOCK (UNC 4 40)+SPL.WASHER
TYPE OF CONTACTS
S-SOCKET
MOUNTING OPTIONS
GX->HARPOON+INSERT UNC 4 40+METAL BRACKET
TYPE OF TERMINATION
33-ANGLED SPILL
PITCH 2.84 USA
FOOT PRINT 8.08 USA
PLATING
4->FLASH Au+Sn/SnPb
6->0.76
µ
Au+Sn/SnPb
METAL BRACKET
HARPOON
CLINCH NUT
SCREW LOCK
WASHER
:
:
:
:
:
HEIGHT OF TERMINATION
"This LF product meets European Union Directives and other country
regulations as described in GS-22-008"
The housing will withstand exposure to 260°C peak temperature for 3.5 seconds
E-3.18 US STANDARD
ELECTRICAL DATA
MAX.CURRENT RATING
TEST VOLTAGE
RATED VOLTAGE
CONTACT RESISTANCE
SHELL RESISTANCE
INSULATION RESISTANCE
:
:
:
:
:
:
5A
1000V
300V
< 25m
Ω
< 5m
Ω
> 5000M
Ω
in a wave solder application with a 1.6mm minimum thick circuit board.
Packaging as per GS-14-920
DELTA-D
E
I06-0074
GVJ
2006/06/08
.00±0.1
0°±1°
.000±.00X
GEORGE.V.JOSEPH
GEORGE.V.JOSEPH
GEORGE.V.JOSEPH
K_V_SIVADAS
E
1
16/12/1998
16/12/1998
22/06/2006
22/06/2006
ENVIRONMENTAL CHARACTERISTICS.
OPERATING TEMPERATURE RANGE
:
-55°C +125°C
MECHANICAL CHARACTERISTICS
MATING/UNMATING CYCLES (MIN)
INSERTION/EXTRACTION FORCE PER CONTACT
:
:
200 (FLASH Au); 500 (0.76µ Au)
5 N Max./ 0.3 N Min.
C-DD-0019
6
PDM: Rev:E
STATUS:
Released
Printed: Jan 18, 2011
.
