4GBJ4005 thru 4GBJ410
GLASS PASSIVATED
BRIDGE RECTIFIERS
FEATURES
●
Surge overload rating -150 amperes peak
●
Ideal for printed circuit board
●
Reliable low cost construction utilizing molded plastic
? .134(3.4)
? .122(3.1)
.995(25.3)
.983(24.7)
REVERSE VOLTAGE
FORWARD CURRENT
4GBJ
- 50
to
1000Volts
- 4.0
Amperes
technique
●
The plastic material has UL flammability
.382(9.7)
.366(9.3)
.189(4.8)
.173(4.4)
.150(3.8)
.134(3.4)
? .134(3.4)
? .122(3.1)
.114(2.9)
.098(2.5)
.031(0.8)
.023(0.6)
.043(1.1)
.035(0.9)
.303(7.7) .303(7.7) .303(7.7)
SPACING
.287(7.3) .287(7.3) .287(7.3)
Dimensions in inches and (milimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Single phase, half wave ,60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward (with heatsink Note 2)
Rectified Current
@ T
C
=100℃ (without heatsink)
Peak Forward Surge Current
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load (JEDEC Method)
Maximum Forward Voltage at 4.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
I
2
t Rating for Fusing (t<8.3ms)
Typical Junction Capacitance Per Element (Note1)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
@ T
J
=25℃
@ T
J
=125℃
SYMBOL
V
RRM
V
RMS
V
DC
I
(AV)
4GBJ
4005
50
35
50
4GBJ
401
100
70
100
4GBJ
402
200
140
200
.074(1.9)
.059(1.5)
4GBJ
404
400
280
400
4.0
2.4
120
1.1
10.0
500
93
45
2.2
-55 to +150
-55 to +150
4GBJ
406
600
420
600
.708(18.0)
.669(17.0)
.150(3.8)
.130(3.3)
.057(1.45)
.041(1.05)
.083(2.1)
.069(1.7)
+
~
~
-
.157
(4.0)
●
Mounting postition:Any
.602(15.3)
.578(14.7)
classification 94V-0
.118(3.0)*45°
4GBJ
408
800
560
800
4GBJ
410
1000
700
1000
UNIT
V
V
V
A
I
FSM
V
F
I
R
I
2
t
C
J
R
θJC
T
J
T
STG
A
V
μA
A
2
s
pF
℃/W
℃
℃
NOTES: 1.Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
2.Device mounted on 50mm*50mm*1.6mm Cu plate heatsink.
~ 486 ~
RATING AND CHARACTERTIC CURVES
4GBJ4005 thru 4GBJ410
FIG.2-MAXIMUM NON-REPETITIVE SURGE CURRENT
PEAK FORWARD SURGE CURRENT,
AMPERES
150
125
100
75
50
25
0
0
2
5
10
20
50
100
NUMBER OF CYCLETS AT 60Hz
FIG.1-FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD CURRENT
AMPERES
5.0
WITH HEATSINK
4.0
3.0
2.0
1.0
0.0
25
50
75
100
125
150
SINGLE PHASE HALF WAVE 60H
Z
RESISTIVE OR INDUCTIVE LOAD
T
J
=150°C
HALF-SINE-WAVE
(JEDEC METHOD)
WITHOUT HEATSINK
SINGLE HALF-SINE-WAVE
(JEDEC METHOD)
CASE TEMPERATURE,
°C
FIG.4-TYPICAL FORWARD CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT,(A)
1000
FIG.5-TYPICAL REVERSE
CHARACTERISTICS
T
J
=150°C
T
J
=150°C
INSTANTANEOUS REVERSE CURRENT,
(uA)
1.0
T
J
=25°C
100
T
J
=125°C
T
J
=100°C
0.1
10
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
INSTANTANEOUS FORWARD VOLTAGE,VOLTS
1.0
T
J
=25°C
0.1
0
20
40
60
80 100
120 140
PERCENT OF RATED PEAK REVERSE VOLTAGE,(%)
FIG.5-TYPICAL JUNCTION CAPACITANCE
100
CAPACITANCE,(pF)
50
T
J
=25°C,f=1MH
Z
10
1.0
10.0
100
REVERSE VOLTAGE,(VOLTS)
