BPF2450T3216C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> BPF2450T3216C

BPF2450T3216C: Description2450 MHz, DIELECTRIC BPF; CategoryAnalog mixed-signal IC filter; File Size71KB，1 Pages; ManufacturerRakon Limited

Download Datasheet Parametric View All

BPF2450T3216C Overview

2450 MHz, DIELECTRIC BPF

BPF2450T3216C Parametric

Parameter Name	Attribute value
Maker	Rakon Limited
Reach Compliance Code	unknown
Other features	TAPE AND REEL
Center frequency or cutoff frequency (fo/fc)	2450 MHz
filter type	DIELECTRIC BPF
high	0.85 mm
Maximum insertion loss	2.5 dB
length	3.2 mm
Manufacturer's serial number	BPF2450T3216C
Installation type	SURFACE MOUNT
physical size	L3.2XB1.6XH0.85 (mm)/L0.126XB0.063XH0.033 (inch)
voltage standing wave ratio	2
width	1.6 mm

Preview

Download Datasheet

View All

TEMEX

DIELECTRIC MATERIALS

Low cost LTCC components

Low Pass Filters

Part

Number

LPF 0870 T 1608

LPF 0898 T 3216

LPF 1748 T 3216

LPF 1810 T 1608

LPF 1880 T 1608

LPF 2442 T 3216

LPF 2450 T 2012

LPF 5513 T 2012

Frequency

Range

(MHz)

824 / 915

880 / 915

1'710 / 1'785

1'710 / 1'910

1'850 / 1'910

2'400 / 2'483

2'400 / 2'500

5'150 / 5'875

Dimensions (mm/inch)

Length

Width

Insertion

Attenuation (dB)

Loss

Thickness

@BW (dB) 2.Fo 3.Fo

4.Fo

0.6 max 20 min 15 min

0.6 max 30 min 18 min

0.6 max 25 min 20 min

0.6 max 27 min 19 min

0.6 max 30 min 18 min

0.6 max 25 min 20 min

VSWR

1.8 max

1.7 max

1.8 max

4,000

3,000

4,000

Qty

per

Reel

4,000

3,000

1.60 / 0.063 0.80 / 0.031 0.60 / 0.024

3.20 / 0.126 1.60 / 0.063 0.85 / 0.033

1.60 / 0.063 0.80 / 0.031 0.60 / 0.024

3.20 / 0.126 1.60 / 0.063 0.85 / 0.033

2.00 / 0.079 1.25 / 0.049 0.85 / 0.033

0.5 max 27 min 25 min 25 min 1.8 max

Band Pass Filters

Part

Number

Frequency

Range

(MHz)

Dimensions (mm/inch)

Length

Width

Insertion

Loss

Thickness

@BW (dB)

1.8 max

2.5 max

(dB)

30@880/915

40@880/915

40@900/928

Attenuation (min)

(dB)

30@1710/1785

42@1710/1990

30@1750

40@1200/1800

30@1200/1800

30@2100

30@1710/1785

20@4600

20@ 4600

III

(dB)

25@1850/1910

30@2100

25@2100

12@2200

TEMEX reserves the right to modify herein speciﬁcations and information at any time when necessary to provide optimum performance and cost.

BPF 2450 T 2520 A 2'400 / 2'500

BPF 2450 T 2520 B 2'400 / 2'500

BPF 2450 T 3216 A 2'400 / 2'500

BPF 2450 T 3216 B 2'400 / 2'500

BPF 2450 T 3216 C 2'400 / 2'500

BPF 2450 T 3225 A 2'400 / 2'500

BPF 2450 T 3225 B 2'400 / 2'500

BPF 2450 T 3225 C 2'400 / 2'500

BPF 5488 T 2012 A 5'150 / 5'825

BPF 5488 T 2012 B 5'150 / 5'825

BPF 5488 T 2012 C 5'150 / 5'825

BPF 5513 T 2012 A 5'150 / 5'875

BPF 5513 T 2012 B 5'150 / 5'875

2.50 / 0.098 2.00 / 0.079 0.90 / 0.035

3.20 / 0.126 1.60 / 0.063 0.85 / 0.033

3.20 / 0.126 2.50 / 0.098 1.50 / 0.059

2.00 / 0.079 1.25 / 0.049 0.85 / 0.033

VSWR @ BW

2.0 max

2.2 max

Qty per Reel

3,000

2,000

4,000

2.5 max 40@1200/1800

2.3 max 40@1200/1800

1.3 max

2.8 max

1.5 max

2.5 max

30@880/915

30@500/4000

30@3500

30@500/4000

20@1850/1910

25@10300/11800

15@10300/11800

1.8 max 35@2570/2900 22@10300/11650 30@15450/17475

1.8 max 35@2570/2900 27@10300/11650 20@15450/17475

Part Number

BPF 2450 T 2520 A

BPF 2450 T 2520 B

BPF 2450 T 3216 A

BPF 2450 T 3216 B

BPF 2450 T 3216 C

BPF 2450 T 3225 A

BPF 2450 T 3225 B

BPF 2450 T 3225 C

BPF 5488 T 2012 A

BPF 5488 T 2012 B

BPF 5488 T 2012 C

BPF 5513 T 2012 A

BPF 5513 T 2012 B
